AIR-AP1810W-Q-K9, Cisco AIR-AP1810W Series Access Point, 802.11ac Wave 2/2x2:2 MIMO/3 GbE Ports

Brand: Cisco · SKU: AIR-AP1810W-Q-K9 · MPN: AIR-AP1810W-Q-K9 · Category: Networking

AIR-AP1810W-Q-K9, Cisco AIR-AP1810W Series Access Point, 802.11ac Wave 2/2x2:2 MIMO/3 GbE Ports
Request for Quote
In Stock • 10 units

802.11ac Wave 2 Access Point, 2x2:2, 3 GbE, Q Regulatory Domain

View Wireless APs Products

Specifications

ModelAIR-AP1810W-Q-K9
System512 MB DRAM; 256 MB flash; 1.4 GHz system dual-core CPU
MountingMounting bracket AIR-AP-BRACKET-W2 for single gang or international standards (included); Optional: AIR-AP1810W-KIT= spacer kit, AIR-OEAP1810-CRD= desk cradle kit
SoftwareCisco Unified Wireless Network Software with AireOS Wireless Controllers Release 8.2.111.0 or later
BluetoothIntegrated Bluetooth 4.1 (including BLE) radio; Max transmit power: 5 dBm; Antenna gain: 2 dBi
IndicatorsStatus LED for boot loader, association, operation, warnings, errors; Per-port status for Ethernet ports. LEDs off by default after joining a controller for privacy; can be enabled administratively
InterfacesOne 10/100/1000BASE-T PoE uplink port; Management console port (RJ-45); Three 10/100/1000BASE-T local Ethernet ports (one PoE out); One passive pass-through port RJ-45; DC power connector. PoE out: 802.3af with local power supply or ~6.5W with 802.3at, no output on 802.3af in
Power DrawMax: 12.95W (15.4W with 100m cable) no PoE out, 20.7W (22W/100m cable) with 6.49W PoE out, 27.65W with 12.95W PoE out (AIR-PWR-C or AIR-PWR-D)
AccessoriesSpare bracket (AIR-AP-BRACKET-W2=), Spacer kit (AIR-AP1810W-KIT=), Cradle kit (AIR-OEAP1810-CRD=), Physical security kit (AIR-SEC-50=), Local power supply (AIR-PWR-D=)
EnvironmentalStorage temp: -30°C to 70°C; Storage max altitude: 25°C, 4500 m; Operating temp: 0°C to 40°C; Operating humidity: 10% to 90% (noncondensing); Operating max altitude: 40°C, 3000 m
Ethernet PortsAuthentication with 802.1X or MAC filtered; Dynamic VLAN or per port; Traffic locally switched or tunneled to WLAN controller
Maximum Clients200 clients per Wi-Fi radio, total 400 clients per access point
Powering Options802.3af/at Ethernet switch; Optional Cisco power injectors (AIR-PWRINJ5=, AIR-PWRINJ6=); Optional Cisco local power supply (AIR-PWR-C= or AIR-PWR-D=)
802.11ac Wireless2x2 single-user/multiuser MIMO with two spatial streams; Maximal ratio combining (MRC); 20/40/80 MHz channels; PHY data rates up to 866.7 Mbps (80 MHz, 5 GHz); Packet aggregation (A-MPDU Tx/Rx, A-MSDU Rx); 802.11 Dynamic Frequency Selection (DFS); Cyclic shift diversity (CSD)
Physical SecurityTorx security screw (included); Kensington security slot
Integrated Antennas2.4 GHz: 2 dBi gain; 5 GHz: 4 dBi gain
Dimensions (W x L x H)6.5 x 4.5 x 1.6 in (165 x 114 x 41 mm) without mounting bracket
Input Power Requirements44–57V DC; Optional power supply and injector: 100–240V AC, 49–60 Hz
Authentication and SecurityAdvanced Encryption Standard (AES) for WPA2; 802.1X; RADIUS authentication, authorization and accounting (AAA); 802.11i
Warranty3-Year Warranty

Key Features

  • OEM Genuine Component verified by certified technicians.
  • Clean serial number ready for service contract registration.
  • Electrostatic Discharge (ESD) safe packaging.
  • Supports hot-swapping for zero-downtime maintenance.

Frequently Asked Questions

Is this product genuine OEM?

Yes, this AIR-AP1810W-Q-K9, Cisco AIR-AP1810W Series Access Point, 802.11ac Wave 2/2x2:2 MIMO/3 GbE Ports (AIR-AP1810W-Q-K9) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.

What warranty is included?

This AIR-AP1810W-Q-K9, Cisco AIR-AP1810W Series Access Point, 802.11ac Wave 2/2x2:2 MIMO/3 GbE Ports includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.

How long does shipping take?

We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.

Can I return this product?

Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.

Is the AIR-AP1810W-Q-K9, Cisco AIR-AP1810W Series Access Point, 802.11ac Wave 2/2x2:2 MIMO/3 GbE Ports compatible with my system?

Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the AIR-AP1810W-Q-K9.
