Key Features:

• Seamless Server Expansion: that supports up to 12 x 2.5-inch or 3.5-inch SAS HDD or SSD in a 2U array, with the ability to expand up to 8 arrays behind a single PERC H800 Host RAID adapter.

• Drive Flexibility: It matches 2.5-inch and 3.5-inch enclosures behind a single adapter, and it supports 7.2K, 10K, and 15K RPM SAS HDDs.

• Data Tiering: that supports a range of drive types to match data requirements and optimize storage efficiency for different applications.

• Redundant Path: with I/O load balancing to ensure continuous data access even if one path fails.

• Self-Encrypting Drives (SED): offer drive-level encryption for data security and instant secure erase for safe decommissioning of drives.

• Hot-swappable drives: to enable easy drive replacement without shutting down the system and ensure minimal disruption.

Specifications:

• Model: Dell PowerVault MD1200

• Disc-Tech: DEL-MD1200-NP-OE

• Interface Types: SAS

• Form Factor: 3.5" LFF Hard Drive

• Bays/Ports/Slots: 12

• U Height: 2U

• Voltage: 110-240V Multi

• Drive Bays: 12 x 3.5-inch or 2.5-inch hot-swappable drive bays

• Drive Compatibility: Supports SAS, SATA, and SSD drives (requires proper RAID controller)

• RAID Support: RAID 0, 1, 5, 10, 50, 60

• Data Transfer Rate: 6 Gbps per port (SAS interface)

• Controller Compatibility: Works with Dell PERC (PowerEdge RAID Controllers)

• Power Supply: Dual, redundant 500W power supplies for increased reliability

• Cooling: Dual redundant cooling fans for efficient heat management

• Expansion: Can be daisy-chained with additional MD1200 or MD1220 arrays for increased capacity

• Management: Managed via Dell Open Manage Storage Console or web-based interface

The Dell Power Vault MD1200 is a reliable and high-capacity storage solution for your business needs. It is a flexible and affordable solution for servers and applications. Moreover, Server Tech Central products are backed by a warranty so you can rely on us. We also provide consistent support before, during, and after the sale.
