Key Features

• 12 x 3.5" LFF drive bays

• 12Gb/s SAS Interface

• Hot-Swap Drive Support

• Dual redundant power supply/cooling fan

• Compatibility: Dell Compellent SC400 Expansion Storage Array is compatible with Dell Compellent SC4020,  Dell Compellent SC5020, Dell Compellent SC7020 and Dell Compellent SC9000

Specifications:

• Brand: Dell

• Dell Equallogic Compellent Part #/MPN: SC400

• Form Factor: 3.5" LFF Hard Drive

• Bays/Ports/Slots: 12

• Hardware & Performance specifications

• Drive Bays: 12 x 3.5" hot-swappable bays

• Drive Interface: 12Gb/s SAS

• Supported Drives:

• SAS HDDs (up to 12TB+ per drive)

• SAS SSDs

• Dual-port, enterprise-grade drives

• 2.5" drives with 3.5" interposers

• Host Interface: 12Gb/s SAS (dual path)

• SAS Expansion Ports: 4 x mini-SAS HD (SFF-8644) connectors (2 in / 2 out)

• Power Supplies: Dual hot-plug redundant power supplies (580W or 700W, depending on model)

• Cooling Fans: Redundant hot-swappable cooling modules

• Input Voltage: Auto-ranging 100–240V AC

• Power Consumption: Approx. 250–350W (typical, depending on drive load)

• Management & Integration:

• Managed via attached SC Series controller (e.g., SC4020/5020/7020/9000)

• Not a standalone storage system – must be part of an SC storage network

• Operating Temperature: 10°C to 35°C (50°F to 95°F)

• Non-operating Temperature: -40°C to 65°C

• Humidity (Operating): 20% to 80% (non-condensing)

• Acoustic Noise: < 7.5 bels (depending on configuration)

• Height: 5.12 in (130 mm)

• Width: 17.6 in (447 mm)

• Weight: Approx. 25–30 kg (depending on the drive population)

• Compliance & Certifications

• ENERGY STAR compliant (depends on configuration)

• RoHS, WEEE, and other global environmental standards

If you are looking for a reliable storage solution for your organization, then the Dell Compellent SC400 Expansion Storage Array is the best option. At Servertechcentral, we deal in centralised storage systems, including storage arrays that meet exceptional standards of capacity, scalability, and redundancy. You can rely on us as we prefer customer-centric values in terms of services, quality, and cost.
