Industrial Hardened Design is built to operate in conditions like wide temperature range, shock resistance, vibration, and electrical hazards. So, the IE-1000-8P2S-LM Cisco Switch is a cost-effective option for industries such as manufacturing, transportation, and utilities looking for a reliable network infrastructure.

Key Features:

• 8 x 10/100Base-TX PoE+ Ports: They deliver power and data over a single Ethernet cable to devices including IP cameras, wireless access points, and sensors.

• Slots: 2 x 100/1000 SFP Slots provide adaptable fiber uplink configurations for long-distance connectivity and fast uplinks.

• Form Factor: DIN Rail Mounting is easy to install in control panels or industrial enclosures.

• Industrial Hardened Design: It is built to operate in conditions like wide temperature range, shock resistance, vibration, and electrical hazards.

• Security Features: Supports port security, DHCP snooping, and Access Control Lists (ACLs) for Network Isolation and threat reduction.

• Fanless Operation: Energy-efficient design ideal for installation in sound-sensitive areas.

Specifications:

• Product Name: Cisco IE-1000-8P2S-LM

• Product Type: Industrial Ethernet Layer 2 Managed Switch

• Ports: 8 x 10/100BASE-TX RJ-45 ports (PoE+ supported), 2 x 100/1000BASE-X SFP combo uplink ports

• PoE Support: Supports IEEE 802.3af (PoE) and 802.3at (PoE+), Up to 30W per port, Total PoE power budget: 240W

• Switching capacity: 4 Gbps

• Forwarding rate: 2.98 Mpps

• MAC address table: 8,000 entries

• Packet buffer size: 1 MB

• Management interfaces: CLI, Web GUI, SNMP v1/v2c/v3

• Management protocols: Telnet, SSH, HTTP, HTTPS, SNMP, RMON

• Software image: LAN Lite (LM)

• Input voltage range: 18V to 60V DC

• Mounting: DIN rail (standard), optional wall mount

• Cooling: Fanless (passive)

• Dimensions (H x W x D): 132 mm x 50 mm x 100 mm

• Weight: Approx. 0.9 kg

• Layer 2 specifications

  • VLANs (IEEE 802.1Q) – up to 256 VLANs

  • STP, RSTP (IEEE 802.1D, 802.1w)

  • IGMP snooping

  • Port-based QoS (IEEE 802.1p)

  • Link Aggregation (LACP – IEEE 802.3ad)

  • Port mirroring

• Security Features

  • IEEE 802.1X port-based authentication

  • Port security

  • DHCP snooping

  • Access Control Lists (ACLs)

  • Secure management via HTTPS and SSH

• Certifications and Compliance

• EMC/EMI: EN 61000-6-2, EN 61000-6-4

• Safety: UL 508, CSA C22.2, ISA 12.12.01 (Class I Div 2)

• Substation compliance: IEEE 1613, IEC 61850-3

• Environmental: RoHS compliant

• Compatibility: Cisco IE-1000-8P2S-LM Switch is compatible with:

• IEEE Standards Supported: IEEE 802.3 (10BASE-T Ethernet), IEEE 802.3u (100BASE-TX Fast Ethernet), IEEE 802.3x (Full Duplex and Flow Control), IEEE 802.3af (Power over Ethernet - PoE), IEEE 802.3at (Power over Ethernet Plus - PoE+), IEEE 802.3z (1000BASE-X for SFP), IEEE 802.1D (Spanning Tree Protocol), IEEE 802.1w (Rapid Spanning Tree, IEEE 802.1Q (VLAN Tagging), IEEE 802.1p (QoS / Priority Tagging), IEEE 802.3ad (Link Aggregation – LACP)

• Cisco 100 Mbps and 1 Gbps SFP transceivers, including: GLC-SX-MM – 1000BASE-SX SFP (multimode fiber, 850nm), GLC-LH-SM – 1000BASE-LX/LH SFP (single-mode fiber, 1310nm), GLC-T – 1000BASE-T SFP (RJ-45 copper), GLC-FE-100FX – 100BASE-FX SFP (multimode fiber), GLC-FE-100LX – 100BASE-LX SFP (single-mode fiber).

• Network monitoring and management tools: Cisco Industrial Network Director (IND), Cisco DNA Center (basic visibility if supported), Cisco Prime Infrastructure, SNMP-based tools (v1/v2c/v3 support), and Web GUI, CLI (via console or SSH).

Cisco IE-1000-8P2S-LM Switch is a powerful and compact Ethernet Switch ideal for challenging industrial environments. With 8 PoE+ capable Fast Ethernet ports and 2 SFP uplink ports, it offers adaptable deployment for IP cameras, access points, and sensors, and delivers high-speed connectivity to the backbone network. Its Layer 2 management capabilities, advanced security features, and compliance with industrial certifications make it reliable for industrial mechanization and other  IoT uses.
