AIR-AP1815I-H-K9C, Cisco Aironet 1815i Series, Wireless Access Point, 867Mbps, 2x2 MIMO, Internal Antenna
Brand: Cisco · SKU: AIR-AP1815I-H-K9C · MPN: AIR-AP1815I-H-K9C · Category: Networking
Cisco Aironet Mobility Express 1815i Series, Reg Domain H
Specifications
| Note | Channel and power settings vary by regulatory domain. Refer to product documentation for regulatory details. |
|---|---|
| Model | AIR-AP1815I-H-K9C |
| Mounting | Mounting bracket AIR-AP-BRACKET8 (included) |
| Software | Cisco Unified Wireless Network Software with AireOS Wireless Controllers Release 8.5 or later, Cisco Mobility Express |
| Bluetooth | Integrated Bluetooth 4.1 (BLE), max transmit power 4 dBm, antenna gain 2 dBi |
| Compliance | Safety: UL 60950-1, CAN/CSA-C22.2 No. 60950-1, UL 2043, IEC 60950-1, EN 60950-1 Radio: FCC Part 15.247/15.407/15.107/15.109, RSS-247, EN 300.328/301.893/301.489-1/301.489-17, ARIB-STD 66/T71, ICES-003, VCCI, EN 50385 IEEE: 802.11a/b/g/n/h/d/ac Security: 802.11i, WPA2, WPA, 802.1X, AES, EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, PEAP v0/v1, EAP-FAST, EAP-GTC, EAP-SIM Multimedia: Wi-Fi Multimedia (WMM) Other: FCC Bulletin OET-65C, RSS-102 |
| Indicators | Status LED for boot, association, operation, warnings, errors |
| Interfaces | 1 x 10/100/1000BASE-T RJ-45 (PoE); management console port (RJ-45) |
| Power Draw | 8.3 W max (on PoE) |
| Accessories | Mounting bracket AIR-AP-BRACKET8= (spare); Physical security kit AIR-SEC-50= (sold separately), includes security screws, RJ-45 caps, unlock keys |
| Environmental | Operating temperature: 0°C to 40°C; humidity: 10%–90% noncondensing; max altitude: 3000 m at 40°C Nonoperating: –30°C to 70°C; humidity: 10%–90% noncondensing; max altitude: 4500 m at 25°C |
| Ethernet Ports | Authentication: 802.1X or MAC filtered; dynamic VLAN or per port; traffic locally switched or tunneled to WLAN controller |
| Maximum Clients | 200 clients per Wi-Fi radio, 400 clients per access point |
| System Hardware | 1 GB DRAM; 256 MB flash; 710 MHz quad-core CPU |
| Powering Options | 802.3af/at Ethernet switch; optional Cisco injectors (AIR-PWRINJ5=, AIR-PWRINJ6=) |
| 802.11ac Features | 2x2 SU-MIMO/MU-MIMO, two spatial streams, maximal ratio combining (MRC), 20/40/80 MHz channels, PHY data rates up to 866.7 Mbps (80 MHz, 5 GHz), A-MPDU (Tx/Rx), A-MSDU (Rx), 802.11 DFS, cyclic shift diversity (CSD) |
| Physical Security | Torx security screw (included) |
| Integrated Antennas | 2.4 GHz: 2 dBi gain; 5 GHz: 4 dBi gain |
| Data Rates Supported | 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps 802.11n (2.4 GHz): Up to 144.4 Mbps (GI = 400 ns), up to 130 Mbps (GI = 800 ns) 802.11ac (5 GHz): Up to 866.7 Mbps (2 streams, 80 MHz, GI = 400 ns) |
| Dimensions (W x L x H) | 6 x 6 x 1.3 in (150.8 x 150.8 x 33 mm), without mounting bracket |
| Transmit Power Settings | 2.4 GHz: 20/17/14/11/8/5/2/–1 dBm (100 to 0.78 mW) 5 GHz: 20/17/14/11/8/5/2/–1 dBm (100 to 0.78 mW) (Max varies by channel/country. Refer to documentation.) |
| Input Power Requirements | Power injector: AIR-PWRINJ5= or AIR-PWRINJ6= |
| Supported WLAN Controllers | Cisco 2500, 3500, 5500, 7500, 8500, 9800 Series Wireless Controllers; Cisco Wireless Controller Module for ISR G2; Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500; Cisco Mobility Express |
| Authentication and Security | Advanced Encryption Standard (AES) for WPA2, 802.1X, RADIUS authentication, authorization, accounting (AAA), 802.11r, 802.11i |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this AIR-AP1815I-H-K9C, Cisco Aironet 1815i Series, Wireless Access Point, 867Mbps, 2x2 MIMO, Internal Antenna (AIR-AP1815I-H-K9C) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This AIR-AP1815I-H-K9C, Cisco Aironet 1815i Series, Wireless Access Point, 867Mbps, 2x2 MIMO, Internal Antenna includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the AIR-AP1815I-H-K9C, Cisco Aironet 1815i Series, Wireless Access Point, 867Mbps, 2x2 MIMO, Internal Antenna compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the AIR-AP1815I-H-K9C.
