MSI K8T NEO-V Retail Socket 939 ATX
Brand: MSI · SKU: K8T NEO-V · MPN: K8T NEO-V · Category: Components
MSI K8T NEO-V Retail, AMD, Socket 939, 4 GB, 10/100/1000 Fast Ethernet, ATX, ATX
Specifications
| Audio output | 7.1 RealTek ALC850 |
|---|---|
| Expansion slots | 1x PCI Express x16 1x PCI Express x4 1x PCI Express x1 4x 32-bit v2.3 Master PCI |
| Processor socket | Socket 939 |
| Power source type | ATX |
| Networking features | 10/100/1000 Fast Ethernet |
| Processor manufacturer | AMD |
| Maximum internal memory | 4 GB |
| Motherboard form factor | ATX |
| Warranty | 3-Year Warranty |
Product Description
CPU Supports Socket 939 for AMD® Athlon™ 64 FX / Athlon™ 64 processor Supports up to 3500+, 3800+, Athlon 64 FX 53(55), or higher CPU Chipset NVIDIA® nForce4 Chipset HyperTransport link to the AMD Athlon 64/Athlon 64 FX CPU HyperTransport supporting speed up to 1GHz (2000MT/s) Supports PCI Express x16/x1 interface Two independent SATA controllers, for four drives Dual Fast ATA-133 IDE controllers IEEE 802.3 NVIDIA MAC for 1000BASE-T Main Memory Supports dual channel DDR 266/333/400, using four 184-pin DDR DIMMs. Supports a maximum memory size up to 4GB without ECC. Supports 2.5v DDR SDRAM DIMM. Slots One PCI Express x16 slot (supports PCI Express Bus specification v1.0a compliant) One PCI Express x4 slots (support PCI Express x2 only) One PCI Express x1 slots (support PCI Express Bus specification v1.0a compliant) Four 32-bit v2.3 Master PCI bus slots (support 3.3v/5v PCI bus interface). On-Board IDE An IDE controller on the NVIDIA nForce4 chipset provides IDE HDD/CD-ROM with PIO, Bus Master and Ultra DMA133/100/66 operation modes. Can connect up to 4 IDE devices On-Board SATA NV RAID supports 4 SATA ports. Transfer rate is up to 150MB/s. NV RAID (Software) Supports up to 4 SATA and 4 ATA133 Hard drives RAID 0 or 1, 0+1, JBOD is supported RAID function available for ATA133+SATA H/D drives Audio 7.1 channel audio codec RealTek ALC850. Compliance with AC97 v2.3 Spec. Meet PC2001 audio performance requirement. LAN Supports Gigabit LAN Supports 10/100/1000 Fast Ethernet by Marvell 88E1111 PHY Internal I/O Connectors ATX 24-Pin power connector 4-pin ATX 12V power connector CPU / System x 2 / NB FAN connectors CD-in connector Clear CMOS jumper Chassis intrusion switch connector 1 x IrDA infrared module header 1 x MSI D-Bracket 2 Connector Front panel audio connector Front panel connector 3 x USB 2.0 connector support additional 6 ports 1 x Floppy disk drive connector 4 x serial ATA connectors 2 x ATA133 HD connectors Back Panel I/O Ports 1 x Parallel 1 x Serial port (COM 1) 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x Coaxial SPDIF out 1 x 6 in 1 Audio jack (S/SPDIF out) 4 x USB 2.0 1 x RJ45 LAN Jack
Key Features
MSI K8T NEO-V Retail. Processor manufacturer: AMD, Processor socket: Socket 939. Maximum internal memory: 4 GB. Networking features: 10/100/1000 Fast Ethernet. Motherboard form factor: ATX, Power source type: ATX. Audio output: 7.1 RealTek ALC850
