P670E-GPON, Huawei OptiXstar P670E Series, GPON Terminal (1GE+1POTS, SC/UPC, 220V)
SKU: HW:P670E-GPON · MPN: HW:P670E-GPON · Category: Components
OptiXstar P670E-GPON terminal-SC/UPC-220V(1GE+1POTS)
Specifications
| NNI | GPON |
|---|---|
| UNI | 1 x GE, 1 x POTS |
| AC Input | 100–240 V AC, 50/60 Hz |
| GPON Port | • Port type: SC/UPC • Complying with ITU-T G.984.2, Class B+ • Receiver sensitivity: –27 dBm to –29 dBm • Overload optical power: –8dBm • Transmission rate: upstream 1.244 Gbit/s, downstream 2.488 Gbit/s • Type B single-homing • Type B dual-homing (supported in Layer 2 forwarding) |
| IP Rating | IP20 |
| POTS Port | • Maximum REN: 4 • G.711A/μ, G.729a/b, and G.722 encoding/decoding • T.30/T.38/G.711 fax mode • DTMF • Emergency calls (with the SIP protocol) |
| Dimensions | Panel: 86 x 86 x 9.5 mm Internal module depth: 35 mm |
| POF Power Input | 48–56 V DC Note: The copper wires in a photoelectric composite cable transmit power in PoE mode and do not transmit data. |
| Surge Protection | GE: common mode 2.5 kV POTS:common mode 2.5 kV AC power: common mode 6 kV; differential mode 4 kV |
| Installation Mode | Indoor 86-box installation |
| Operating Humidity | 5–95% RH (non-condensing) |
| Operating Temperature | –5°C to +40°C |
| Compliance Certification | CE/CCC |
| Ethernet Electrical Port | • Port type: RJ-45 • Auto port speeds (10/100/1000 Mbit/s) • Auto-MDI/MDIX • Configuration of the number of MAC addresses learned • VLAN transparent transmission/VLAN filtering |
| Maximum Power Consumption | P670E: 5.8 W P670E-H: 6.5 W |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this P670E-GPON, Huawei OptiXstar P670E Series, GPON Terminal (1GE+1POTS, SC/UPC, 220V) (HW:P670E-GPON) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This P670E-GPON, Huawei OptiXstar P670E Series, GPON Terminal (1GE+1POTS, SC/UPC, 220V) includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the P670E-GPON, Huawei OptiXstar P670E Series, GPON Terminal (1GE+1POTS, SC/UPC, 220V) compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the HW:P670E-GPON.
