CS-KIT-MINI-SMK, Cisco Screen Mount Kit, For Webex Room Kit Mini/Screen mounting/Accessory
SKU: CS-KIT-MINI-SMK · MPN: CS-KIT-MINI-SMK · Category: Components
Specifications
| Power | ● 100 to 240 VAC, 50/60 Hz, 12V DC input ● Average 20W, peak 70W ● Must be used with power supply FSP FSP070-AHAN2 or AcBel ADF019 |
|---|---|
| Bandwidth | ● Up to 6 Mbps point to point |
| MultiSite | ● H.239 (H.323) dual stream ● Binary Floor Control Protocol (BFCP) (SIP) dual stream ● Supports resolutions up to 3840 x 2160p5 |
| Protocols | ● H.323 ● SIP ● Cisco Webex |
| Dimensions | ● Width: 19.7 in. (50.0 cm) ● Height: 3.2 in. (8.1 cm) ● Depth: 3 in. (7.7 cm) ● Weight: 4 lb. (2 kg) Packaging size ● Width: 23.8 in. (60.5 cm) ● Height: 12.8 in. (32.6 cm) ● Depth: 8.5 in. (21.6 cm) ● Weight: 7 lb. (3.2 kg) |
| Dual stream | ● One HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps, including HD1080p60 ● Consumer Electronics Control (CEC) 2.0 |
| Audio inputs | ● One audio in from HDMI ● Internal microphones ● Bluetooth ® - Not available on Non Radio Version * |
| Call control | ● Cisco Unified Communications Manager (Unified CM) ◦ Native registration with Unified CM ◦ Requires Unified CM Version 9.1(2) or later with device pack Room Kit Mini ● Cisco Expressway ◦ Native registration with Expressway ● Cisco Webex Service ● Third-party H.323 gatekeepers and standards-based SIP proxies |
| Video inputs | ● One HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps, including HD1080p60 ● Consumer Electronics Control (CEC) 2.0 |
| Video outputs | ● 1 HDMI output supports formats up to 3840 x 2160p60 (4Kp60) ● Live video resolutions (encode and decode) up to 1920 x 1080p30 and p60 (HD1080p) ● Consumer Electronics Control (CEC) 2.0 |
| Audio features | ● High-quality 20 kHz audio ● Automatic Gain Control (AGC) ● Automatic noise reduction ● Active lip synchronization |
| Audio standards | ● G.711, G.722, G.722.1, G.729, AAC-LD, and Opus |
| Camera overview | ● 4K UltraHD camera ● Supports up to 30 fps ● 8 MP image sensor ● 1/2.5’’ CMOS ● 5x zoom ● f/1.4 aperture ● 120° horizontal field of view ● Auto framing (face detect) ● Best overview ● Auto brightness, and white balance ● Focus distance 1 m to infinity |
| USB passthrough | ● Ability to join any web conferencing service and share content using the camera, microphones and speakers of Room Kit Mini with a USB cable connected with the external monitor and an HDMI cable connected with the computer ● 720p video resolution |
| Video standards | ● H.264 |
| Other interfaces | ● 1 USB 2.0 port type A ● 1 USB 2.0 port type C ● 1 USB port ● Factory reset pinhole |
| Wireless sharing | ● Webex app (up to 3840 x 2160p5) ● Cisco Intelligent Proximity client (up to 1920 x 1080p5) ● Miracast (1080p30) – Not available on Non radio version |
| Security features | ● Management using HTTPS and SSH ● IP administration password ● Menu administration password ● Disable IP services ● Network settings protection ● Privacy cover |
| Firewall traversal | ● Cisco Expressway™ technology ● H.460.18, H.460.19 firewall traversal |
| Multipoint support | ● 4-way embedded SIP/H.323 conferencing capability with MultiSite option |
| Network interfaces | ● One Ethernet (RJ-45) 10/100/1000 for LAN ● One Ethernet (RJ-45) for Cisco Touch 10 direct pairing ● Wi-Fi 802.11a/b/g/n/ac 2.4 GHz/5 GHz - not available in non-radio versions Note: Due to compliance regulations, it is required that 802.11d is enabled in the access point for the product to operate properly within 5725 MHz – 5875 MHz. Using a Wi-Fi connection is a flexible option, however an Ethernet connection is always preferred for high performance. |
| Embedded encryption | ● H.323 and SIP point to point ● Standards-based: H.235 v3 and Advanced Encryption Standard (AES) ● Automatic key generation and exchange |
| IP network features | ● DNS lookup for service configuration ● Differentiated services (Quality of Service [QoS]) ● IP-adaptive bandwidth management (including flow control) ● Automatic gatekeeper discovery ● Dynamic playout and lip-sync buffering ● H.245 Dual-Tone Multifrequency (DTMF) tones in H.323 ● RFC 4733 DTMF tones in SIP ● Date and time support using Network Time Protocol (NTP) ● Media adaptation and resilience ● Uniform Resource Identifier (URI) dialing ● Dynamic Host Configuration Protocol (DHCP) ● 802.1X network authentication ● 802.1Q Virtual LAN ● 802.1p (QoS and Class of Service [CoS]) |
| IPv6 network support | ● Single call stack support for both H.323 and SIP ● Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ ● Support for both static and automatic IP configuration (stateless address auto configuration) |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this CS-KIT-MINI-SMK, Cisco Screen Mount Kit, For Webex Room Kit Mini/Screen mounting/Accessory (CS-KIT-MINI-SMK) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This CS-KIT-MINI-SMK, Cisco Screen Mount Kit, For Webex Room Kit Mini/Screen mounting/Accessory includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the CS-KIT-MINI-SMK, Cisco Screen Mount Kit, For Webex Room Kit Mini/Screen mounting/Accessory compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the CS-KIT-MINI-SMK.
