AIR-AP1815I-B-K9, Cisco Aironet 1815i Access Point, 802.11ac Wave2/2x2 MIMO/867 Mbps
Brand: Cisco · SKU: AIR-AP1815I-B-K9 · MPN: AIR-AP1815I-B-K9 · Category: Networking
$134.32
In Stock • 10 units
Cisco Aironet 1815i Series (for US), Reg Domain B
Specifications
| Model | AIR-AP1815I-B-K9 |
|---|---|
| Notes | Channel and power settings vary by regulatory domain and country. Refer to product documentation for full compliance details. |
| Mounting | Mounting bracket AIR-AP-BRACKET8 (included) |
| Software | Cisco Unified Wireless Network Software with AireOS (Release 8.5 or later), Cisco Mobility Express |
| Bluetooth | Integrated Bluetooth 4.1 (BLE), max transmit power: 4 dBm, antenna gain: 2 dBi |
| Compliance | Safety: UL 60950-1, CAN/CSA-C22.2 No.60950-1, UL 2043, IEC 60950-1, EN 60950-1 Radio: FCC Part 15.247, 15.407, RSS-247 (Canada), EN 300.328, EN 301.893 (Europe), ARIB-STD 66/ T71 (Japan), VCCI (Japan), EMI & susceptibility (Class B), other IEEE: 802.11a/b/g/n/h/d/ac Security: 802.11i, WPA2, WPA, 802.1X, AES EAP Types: EAP-TLS, EAP-TTLS, MSCHAPv2, PEAP v0/v1, EAP-FAST, EAP-GTC, EAP-SIM Multimedia: WMM Other: EN 301.489-1/-17, EN 50385, FCC Bulletin OET-65C, RSS-102 |
| Indicators | Status LED: boot loader status, association, operation, warnings, errors |
| Interfaces | 1 x 10/100/1000BASE-T (RJ-45, PoE); 1 x management console port (RJ-45) |
| Power Draw | 8.3 W (maximum, on PoE) |
| Accessories | Spare mounting bracket (AIR-AP-BRACKET8=), physical security kit (AIR-SEC-50=, sold separately): security screws, RJ-45 caps, unlock keys |
| Environmental | Operating: 0°C to 40°C (32°F to 104°F), humidity 10%–90% (noncondensing), max altitude 3000 m @ 40°C; Storage: -30°C to 70°C (-22°F to 158°F), humidity 10%–90% (noncondensing), max altitude 4500 m @ 25°C |
| Ethernet Ports | 1 x 10/100/1000BASE-T autosensing (RJ-45), PoE support; authentication with 802.1X or MAC filter, dynamic VLAN or per port, local switch or tunneled to WLAN controller |
| Maximum Clients | 200 clients per Wi-Fi radio, total 400 clients per access point |
| Powering Options | 802.3af/at Ethernet switch, optional Cisco power injectors (AIR-PWRINJ5=, AIR-PWRINJ6=) |
| System Resources | 1 GB DRAM, 256 MB flash, 710 MHz quad-core CPU |
| 802.11ac Features | 2x2 SU/MU MIMO, two spatial streams, maximal ratio combining (MRC), 20/40/80 MHz channels, PHY rates up to 866.7 Mbps (80 MHz @ 5 GHz), A-MPDU (Tx/Rx), A-MSDU (Rx), Dynamic Frequency Selection (DFS), cyclic shift diversity (CSD) |
| Physical Security | Torx security screw (included) |
| Integrated Antennas | 2.4 GHz: 2 dBi gain; 5 GHz: 4 dBi gain |
| Supported Data Rates | 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps; 802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps; 802.11n (2.4 GHz): up to 144.4 Mbps; 802.11ac (5 GHz): up to 866.7 Mbps |
| Dimensions (W x L x H) | 6 x 6 x 1.3 in (150.8 x 150.8 x 33 mm), without mounting bracket |
| Input Power Requirements | Power injector: AIR-PWRINJ5= or AIR-PWRINJ6= |
| Supported WLAN Controllers | Cisco 2500/3500/5500 Series, Wireless Controller Module for ISR G2, WiSM2 for Catalyst 6500, Flex 7500, 8500, 9800 Series, Cisco Mobility Express |
| Authentication and Security | Advanced Encryption Standard (AES) for WPA2, 802.1X, RADIUS authentication, authorization and accounting (AAA), 802.11r, 802.11i |
| Maximum Non-Overlapping Channels | Regulatory domain dependent; e.g., 2.412–2.462 GHz: 11 channels (B, N, T, Z), 2.412–2.472 GHz: 13 channels (C, E, F, G, H, I, K, Q, R, S), 5.180–5.320 GHz: 3–8 channels; full details in product documentation |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this AIR-AP1815I-B-K9, Cisco Aironet 1815i Access Point, 802.11ac Wave2/2x2 MIMO/867 Mbps (AIR-AP1815I-B-K9) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This AIR-AP1815I-B-K9, Cisco Aironet 1815i Access Point, 802.11ac Wave2/2x2 MIMO/867 Mbps includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the AIR-AP1815I-B-K9, Cisco Aironet 1815i Access Point, 802.11ac Wave2/2x2 MIMO/867 Mbps compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the AIR-AP1815I-B-K9.
