ASUS TS300-E5/PA4 server barebone Intel® 3210 LGA 775 (Socket T)
Brand: ASUS · SKU: TS300-E5/PA4 · MPN: TS300-E5/PA4 · Category: Servers
ASUS TS300-E5/PA4, Intel® 3210, LGA 775 (Socket T), Intel, 8 GB, 0, 1, 32 MB
Specifications
| ECC | Yes |
|---|---|
| Depth | 431 mm |
| Width | 220 mm |
| Height | 510 mm |
| Safety | UL1950-CSA950, CE, EN55022, TUV |
| Weight | 18 kg |
| PCI slots | 3 |
| Drive bays | 1 x 5.25" |
| RAID levels | 0, 1 |
| Ethernet LAN | Yes |
| Power supply | 450 W |
| Diskette drive | 1 x FDD, 3 x 5.25" |
| LAN controller | Broadcom BCM5721 |
| Expansion slots | 1 x SO-DIMM |
| Bundled software | ASWM2.0 |
| Processor family | Intel |
| Processor socket | LGA 775 (Socket T) |
| Motherboard chipset | Intel® 3210 |
| PS/2 ports quantity | 2 |
| Number of DIMM slots | 4 |
| PCI Express x8 slots | 1 |
| PCI Express x16 slots | 2 |
| Serial ports quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Warranty | 3-Year Warranty |
| Weight | 18 kg |
| Dimensions | 220 mm x 431 mm x 510 mm |
Product Description
TS300-E5/PA4 is a single-socket pedestal server system based on Intel® 3210MCH chipset, which provides immediate performance scale up and high processing speed in the UP tower server. With 4 DIMM slots, the server supports DDR2 800/667 Un-buffered ECC/Non-ECC up to 8GB memory capacity. Support Latest 45nm Multi-Core Processor Technology - Offer the best performance per Watt - Higher frequency and great energy efficiency Quad-LAN Teaming Technology Provides 200% Faster Transfer Rate - Four enterprise-class PCI-Express Gb LAN provide 200% faster than dual LAN platform - Teaming & Failover function enables higher bandwidth aggregation and reliable network connection - Multiple network segments help enhance network security and improve communication efficiency Superb Storage Expandability and High Availability - Four hot-swappable HDD bays offer mass storage capacity and high system availability - Support RAID 0, 1, 10 for major Linux distributions and RAID 0, 1, 5, 10 for Windows OS Flexible Expansion Choices - Provide three 32-bit/33MHz (5V) PCI slots for legacy device support - Provide two PCI-E x 16 (x8 link) and one PCI-E x8 (x1 link) for high bandwidth - One SO-DIMM socket for optional ASUS ASMB3-SOL card for remote management and monitoring User-friendly Server Management - Bundled ASWM2.0 system software makes system management easy. With effective management and monitoring via intelligent interaction & image; the customer may have a clear view regarding CPU, memory, HDD, fan speed, OS, FRU, NIC status
Key Features
ASUS TS300-E5/PA4. Motherboard chipset: Intel® 3210, Processor socket: LGA 775 (Socket T), Processor family: Intel. Maximum internal memory: 8 GB. RAID levels: 0, 1. Maximum graphics card memory: 32 MB. Ethernet interface type: Gigabit Ethernet, LAN controller: Broadcom BCM5721
