QNAP QXP-W6-AX200 network card WLAN / Bluetooth 2400 Mbit/s
Brand: QNAP · SKU: QXP-W6-AX200 · MPN: QXP-W6-AX200 · Category: Components
QNAP QXP-W6-AX200, Wireless, PCI Express, WLAN / Bluetooth, Wi-Fi 6 (802.11ax), 2400 Mbit/s
Specifications
| Wi-Fi | Yes |
|---|---|
| Antenna | Yes |
| Internal | No |
| Bluetooth | Yes |
| Interface | WLAN / Bluetooth |
| Modulation | 1024-QAM |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| Resource CD | Yes |
| Antenna design | External |
| Host interface | PCI Express |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Bluetooth version | 5.0 |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Security algorithms | WEP, WPA-PSK, WPA2-PSK |
| Connectivity technology | Wireless |
| Quick installation guide | Yes |
| Maximum data transfer rate | 2400 Mbit/s |
| Mounting brackets included | Yes |
| Harmonized System (HS) code | 85176990 |
| Operating temperature (T-T) | 0 - 40 °C |
| Linux operating systems supported | Yes |
| Windows operating systems supported | Windows 10 |
| Warranty | 3-Year Warranty |
Product Description
The QXP-W6-AX200 is a PCIe Gen 2x1 Wi-Fi 6 wireless adapter with an Intel Wi-Fi 6 AX200 module that supports the IEEE 802.11ax standard (backwards compatible with 802.11a/b/g/n/ac), MIMO 2Tx2R, MU-MIMO TX/RX and Bluetooth 5.0. The QXP-W6-AX200 can be installed in a QNAP NAS, or Windows/Linux PC to provide fast Wi-Fi 6 connection speeds The QXP-W6-AX200 can also be used with Wi-Fi 6 router to deploy Wi-Fi 6 network environment. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included. 2.8x Faster Connectivity The QXP-W6-AX200 dual band Wi-Fi 6 PCIe card supports 802.11ax 160MHz dual band connectivity, 1024-QAM and up to 2400Mbps connection speed which is 2.8 times faster than Wi-Fi 5(802.11ac). Easy Access with a Wireless NAS With a QXP-W6-AX200 installed in your NAS, you can free yourself from Ethernet cables and access all your stored files and multimedia over a high-speed wireless connection. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included. Easily Set Up a NAS Wireless Network Connection After installing the QXP-W6-AX200 in your NAS, use Network & Virtual Switch or Qfinder Pro to set up the Wi-Fi connection, guest network environment or captive portal. Upgrade Your Windows or Linux PC with High-speed Wireless Networking! The QXP-W6-AX200 is not just for NAS, it can be installed in a Windows or Linux PC to provide Wi-Fi 6 connectivity for enabling faster downloading speeds and low-latency connectivity. Dual Band Antenna with Better Wi-Fi Signals The QXP-W6-AX200 features a new antenna design that provides better Wi-Fi signals and transmission speeds. Supports dual band 802.11ax 2.4GHz & 5GHz and provides better signal strength compared to traditional antenna designs. The smart antenna function provides superior WI-FI signal transmission. The multiple angle tilt and magnetic base allows you to get the best signal strength direction and location. Add Bluetooth 5.0 to Your Windows PC When installed in a Windows PC, the QXP-W6-AX200 provides Bluetooth 5.0 connectivity. Please note that this requires connecting the QXP-W6-AX200 to an F_USB connector on your motherboard using the included USB cable.
Key Features
QNAP QXP-W6-AX200. Connectivity technology: Wireless, Host interface: PCI Express, Interface: WLAN / Bluetooth. Maximum data transfer rate: 2400 Mbit/s, Top Wi-Fi standard: Wi-Fi 6 (802.11ax), Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)
