PVDM3-256, Cisco PVDM3 DSP Module, 256-channel, High-density, Voice/Video
Brand: Cisco · SKU: PVDM3-256 · MPN: PVDM3-256 · Category: Components
256-channel high-density voice and video DSP module
Specifications
| DSP | Multicore DSP technology |
|---|---|
| Model | PVDM3-256 |
| Power | 4.85 W |
| Weight | kg |
| Current | 1.47 A |
| Voltage | 3.3 V |
| Features | Software echo cancellation compliant with ITU-T G.168, with 128 ms tail coverage |
| Interface | 240-pin dual-inline-memory-module (DIMM) interface |
| EMC Flicker | EN61000-3-3 |
| EFT Immunity | EN61000-4-4 |
| Homologation | Platform dependent |
| EMC Harmonics | EN61000-3-2 |
| Surge Immunity | EN61000-4-5 |
| Safety Compliance | Complies with IEC 60950 (worldwide); AS/NZS 60950-1 (Australia and New Zealand); CAN/CSA-C22.2 No. 60950-1, 1st and 2nd Edition (Canada); GB4943-95 (People's Republic of China); EN60950-1, 1st and 2nd Edition (CENELEC; includes EU and EFTA); NOM-019-SCFI-1998 (Mexico); UL 60950-1, 1st and 2nd Edition (United States) |
| RF Fields Immunity | EN61000-4-3 |
| DSP External Memory | 512-megabit double-data-rate (DDR) synchronous dynamic random access memory (SDRAM) for each DSP |
| Conducted RF Immunity | EN61000-4-6 |
| Operating Temperature | -41 to 131 °F (-5 to 55 °C) |
| EMC Immunity Standards | CISPR24; EN55024; EN50082-1 |
| EMC Emissions Standards | CISPR22 Class B; EN55022 Class B; CFR47 Part 15 Subpart B Class B |
| Electrostatic Discharge (ESD) | EN61000-4-2 |
| Power-Frequency Magnetic Fields | EN61000-4-8 |
| Mean Time Between Failure (MTBF) | System dependent |
| Voltage Dips, Sags, and Interruptions | EN61000-4-11 |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this PVDM3-256, Cisco PVDM3 DSP Module, 256-channel, High-density, Voice/Video (PVDM3-256) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This PVDM3-256, Cisco PVDM3 DSP Module, 256-channel, High-density, Voice/Video includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the PVDM3-256, Cisco PVDM3 DSP Module, 256-channel, High-density, Voice/Video compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the PVDM3-256.
