PVDM3-16, Cisco DSP Module, 16-channel voice, High-density, Video support
Brand: Cisco · SKU: PVDM3-16 · MPN: PVDM3-16 · Category: Components
16-channel high-density voice and video DSP module
Specifications
| DSP | Multicore DSP technology |
|---|---|
| Model | PVDM3-16 |
| Weight | kg |
| Current | 1.47 A |
| Voltage | 3.3 V |
| Interface | 240-pin dual-inline-memory-module (DIMM) interface |
| EMC Flicker | EN61000-3-3 |
| Module Type | PVDM3 module |
| EFT Immunity | EN 61000-4-4 |
| ESD Immunity | EN 61000-4-2 |
| Homologation | Platform dependent |
| EMC Emissions | CISPR22 Class B, EN55022 Class B, CFR47 Part 15 Subpart B Class B |
| EMC Harmonics | EN61000-3-2 |
| Surge Immunity | EN 61000-4-5 |
| Echo Cancellation | Software echo cancellation compliant with ITU-T G.168, with 128 ms tail coverage |
| Power Consumption | 4.85 W |
| RF Field Immunity | EN 61000-4-3 |
| Safety Compliance | Complies with IEC 60950 (worldwide) and AS/NZS 60950-1 (Australia and New Zealand), CAN/CSA-C22.2 No. 60950-1, 1st and 2nd Ed. (Canada), GB4943-95 (People's Republic of China), EN60950-1, 1st and 2nd Ed. (CENELEC; includes EU and EFTA), NOM-019-SCFI-1998 (Mexico), and UL 60950-1, 1st and 2nd Ed. (United States) |
| DSP External Memory | 512-megabit double-data-rate (DDR) SDRAM for each DSP |
| Conducted RF Immunity | EN 61000-4-6 |
| Operating Temperature | -41 to 131 °F (-5 to 55 °C) |
| EMC Immunity Standards | CISPR24, EN 55024, EN50082-1 |
| Power-Frequency Magnetic Fields | EN 61000-4-8 |
| Mean Time Between Failure (MTBF) | System dependent |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this PVDM3-16, Cisco DSP Module, 16-channel voice, High-density, Video support (PVDM3-16) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This PVDM3-16, Cisco DSP Module, 16-channel voice, High-density, Video support includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the PVDM3-16, Cisco DSP Module, 16-channel voice, High-density, Video support compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the PVDM3-16.
