StarTech.com Discontinued and replaced by PEX1S953LP - 1 Port Low Profile Native PCI Express RS232 Serial Card with 16950 UART - PCIe Serial Card - 1 Port LP RS232 Card
Brand: StarTech.com · SKU: PEX1S952LP · MPN: PEX1S952LP · Category: Components
StarTech.com Discontinued and replaced by PEX1S953LP - 1 Port Low Profile Native PCI Express RS232 Serial Card with 16950 UART - PCIe Serial Card - 1 Port LP RS232 Card, PCIe, Serial, RS-232, Green, 87600 h, CE, FCC, Microsoft WHQL, REACH
Specifications
| Depth | 90 mm |
|---|---|
| Width | 65 mm |
| Height | 20 mm |
| Manual | Yes |
| Weight | 48 g |
| Chipset | PLX/Oxford - OXPCIe952 |
| Internal | Yes |
| Baud rate | 460.8 Kbit/s |
| Data bits | 4, 5, 6, 7, 8 |
| Stop bits | 1, 1.5, 2 |
| Certification | CE, FCC, Microsoft WHQL, REACH |
| Package depth | 174 mm |
| Package width | 144 mm |
| Host interface | PCIe |
| Package height | 31 mm |
| Package weight | 130 g |
| Product colour | Green |
| Drivers included | Yes |
| Output interface | Serial |
| Serial interface type | RS-232 |
| Serial ports quantity | 1 |
| Compliance certificates | RoHS |
| Master (outer) case width | 357 mm |
| Storage temperature (T-T) | -20 - 100 °C |
| Warranty | 3-Year Warranty |
| Weight | 48 g |
| Dimensions | 65 mm x 90 mm x 20 mm |
Product Description
Add 1 high-speed serial RS-232 port to any PC with a PCI Express slot The PEX1S952LP 1 Port Low Profile Native PCI Express RS232 Serial Adapter Card with 16950 UART adds an RS232 (DB9) Serial Port with data rates up to 460 Kbps to a computer through an available low profile PCIe slot, while relying on a native, single-chip design (Oxford OXPCIe952) that harnesses the capability of true PCI Express - ensuring maximum performance and reliability and reducing the load applied to the CPU by as much as 48% over conventional (bridge chip) serial cards. The 1 port RS232 serial card features a half-height pci express mounting bracket that's designed specifically for low profile/small form factor computer cases, and includes an optional standard height bracket as well. Compatible with a broad range of operating systems including Windows and Linux for easy integration into mixed environments. Backed by a StarTech.com lifetime warranty and free lifetime technical support. The StarTech.com Advantage - Low profile bracket installed for installation into small form-factor systems - Reduced CPU load and increased performance via native single-chip design - 460 Kbps data rates offer efficient serial device performance
Key Features
StarTech.com Discontinued and replaced by PEX1S953LP - 1 Port Low Profile Native PCI Express RS232 Serial Card with 16950 UART - PCIe Serial Card - 1 Port LP RS232 Card. Host interface: PCIe, Output interface: Serial, Serial interface type: RS-232. Product colour: Green, Mean time between failures (MTBF): 87600 h, Certification: CE, FCC, Microsoft WHQL, REACH. Chipset: PLX/Oxford - OXPCIe952, Baud rate: 460.8 Kbit/s, FIFO (First In, First Out): 128 B. Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10..., Server operating systems supported: Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows..., Other operating systems supported: Windows XP Embedded. Width: 65 mm, Depth: 90 mm, Height: 20 mm
Frequently Asked Questions
Is this product genuine OEM?
Yes, this StarTech.com Discontinued and replaced by PEX1S953LP - 1 Port Low Profile Native PCI Express RS232 Serial Card with 16950 UART - PCIe Serial Card - 1 Port LP RS232 Card (PEX1S952LP) is 100% genuine StarTech.com hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This StarTech.com Discontinued and replaced by PEX1S953LP - 1 Port Low Profile Native PCI Express RS232 Serial Card with 16950 UART - PCIe Serial Card - 1 Port LP RS232 Card includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the StarTech.com Discontinued and replaced by PEX1S953LP - 1 Port Low Profile Native PCI Express RS232 Serial Card with 16950 UART - PCIe Serial Card - 1 Port LP RS232 Card compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the PEX1S952LP.
