ANT5G16D4NW, Huawei ANT5G Series, Directional Antenna
SKU: HW:ANT5G16D4NW · MPN: HW:ANT5G16D4NW · Category: Components
Directional Antenna-5150 ~ 5850MHz-16DBI-25DEG / 25DEG-NFEMALE-4 port-self-supplied mount-wall installation
Specifications
| Gain | 16 dBi |
|---|---|
| VSWR | < 1.5:1 |
| Model | ANT5G16D4NW |
| Mounting | Self-supplied Mount |
| Impedance | 50 Ohms |
| Wind Load | 160 km/h |
| Polarization | Dual Slant ��45�� |
| Product Type | Directional Antenna |
| Connector Type | N Female |
| Frequency Range | 5150 ~ 5850 MHz |
| Max Input Power | 50W |
| Number of Ports | 4 |
| Mounting Options | Wall Installation |
| Antenna Dimensions | 550mm x 160mm x 80mm |
| Ingress Protection | IP65 |
| Front-to-Back Ratio | > 25 dB |
| Beamwidth (Vertical) | 25 degrees |
| Operating Temperature | -40��C to +65��C |
| Beamwidth (Horizontal) | 25 degrees |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this ANT5G16D4NW, Huawei ANT5G Series, Directional Antenna (HW:ANT5G16D4NW) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This ANT5G16D4NW, Huawei ANT5G Series, Directional Antenna includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the ANT5G16D4NW, Huawei ANT5G Series, Directional Antenna compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the HW:ANT5G16D4NW.
