ANT5G16D4NP, Huawei Directional Antenna, 5150~5850MHz/16dBi/4 ports
SKU: HW:ANT5G16D4NP · MPN: HW:ANT5G16D4NP · Category: Components
Directional antenna -5150 ~ 5850MHz-16DBI-25DEG / 25DEG-NFEMALE-4 port - self-belled mount - hugging installation
Specifications
| Gain | 16dBi |
|---|---|
| VSWR | Less than 2.0 |
| Material | Aluminum |
| Impedance | 50 Ohms |
| Wind Load | Low |
| Dimensions | 100mm x 300mm x 100mm |
| Antenna Type | Directional |
| Installation | Hugging Installation |
| Polarization | Dual |
| Product Name | ANT5G16D4NP |
| Mounting Type | Self-belled Mount |
| Connector Type | N Female |
| Frequency Range | 5150 ~ 5850MHz |
| Number of Ports | 4 |
| Relative Humidity | 5% to 95% |
| Vertical Beamwidth | 25 Degrees |
| Front-to-Back Ratio | Greater than 25dB |
| Storage Temperature | -40��C to 85��C |
| Horizontal Beamwidth | 25 Degrees |
| Operating Temperature | -40��C to 70��C |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this ANT5G16D4NP, Huawei Directional Antenna, 5150~5850MHz/16dBi/4 ports (HW:ANT5G16D4NP) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This ANT5G16D4NP, Huawei Directional Antenna, 5150~5850MHz/16dBi/4 ports includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the ANT5G16D4NP, Huawei Directional Antenna, 5150~5850MHz/16dBi/4 ports compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the HW:ANT5G16D4NP.
