ATEN KN9116 KVM switch Black
Brand: ATEN · SKU: DCP3001 · MPN: DCP3001 · Category: Data Center
ATEN KN9116, 1600 x 1200 pixels, 12 W, Black. ATEN KN9116 KVM switch Black (part number DCP3001) is an enterprise kvm switches product available from Server Tech Central. Key specifications include depth 260 mm, width 437 mm, height 44 mm, manual Yes, weight 4.2 kg, console port RS-232, input voltage 100-240 V, scan interval 255 s. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| Depth | 260 mm |
|---|---|
| Width | 437 mm |
| Height | 44 mm |
| Manual | Yes |
| Weight | 4.2 kg |
| Console port | RS-232 |
| Input voltage | 100-240 V |
| Scan interval | 255 s |
| LED indicators | Yes |
| Product colour | Black |
| Mouse port type | PS/2 |
| Video port type | VGA |
| Built-in display | No |
| AC input frequency | 50 - 60 Hz |
| Keyboard port type | PS/2 |
| Maximum resolution | 1600 x 1200 pixels |
| Data link protocols | Fast Ethernet |
| PS/2 ports quantity | 2 |
| Compliance certificates | RoHS |
| Connectivity technology | Wired |
| Storage temperature (T-T) | -20 - 60 °C |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 17 |
| Operating temperature (T-T) | 0 - 40 °C |
| Warranty | 3-Year Warranty |
| Weight | 4.2 kg |
| Dimensions | 437 mm x 260 mm x 44 mm |
Product Description
Features - 16 port remote access KVM switch - monitor and control up to 16 computers from a single KVM (Keyboard, Video, Mouse) console - Remotely access computers via LAN, WAN, or the Internet - control your installation when and where you want - Dual-bus: one local and one remote administrator can simultaneously control separate ports - Internet browser access, Windows Client and Java Client provided; Java Client works with most operating systems - Graphical OSD and graphical toolbars for convenient, user-friendly operation - Cascadable up to 2 levels* - provides up to 128 computers - Up to 64 user accounts - up to 32 concurrent logins - Panel Array Mode - view all 16 ports at the same time - Message board feature allows logged in users to communicate with each other and allows a user to take exclusive control of the KVM functions - Windows-based Log Server - Remote power control for attached Power over the Net™ devices - Three level security: multiadministrator; multiuser; multiviewer - Advanced security features include password protection and advanced encryption technologies - 1024 bit RSA, 256 bit AES, 56 bit DES, and 128 bit SSL - RADIUS server support - Flash upgradable firmware over network connection - Ports can be set to Exclusive, Occupy and Share - Network Interfaces: TCP/IP, HTTP, HTTPS, UDP, RADIUS, DHCP, SSL, ARP, DNS, 10Base-T/100Base-TX, auto sense, Ping - Detachable front panel for easy access to front and rear of unit - High video resolution: up to 1280 x 1024 @ 75Hz; 1600 x 1200 @ 60Hz - Multiplatform support: Windows 2000/XP/Vista, Linux, Unix. * Compatible KVM Switches: KH98, CS9134, CS9138, CS88A, KH1508, KH1516. Some KVM Over the NET™ features may not be supported,depending on the functionality of the cascaded KVM switch. Package Contents - 1x 16-Port KVM Over the NET™ - 2x Custom KVM Cable Sets - 1x Power Cord - 1x Rack Mount Kit - 1x User Instructions - 1x Foot Pads (4pcs.)
Key Features
ATEN KN9116. Keyboard port type: PS/2, Mouse port type: PS/2, Video port type: VGA. Maximum resolution: 1600 x 1200 pixels, Scan interval: 255 s. Product colour: Black. Input voltage: 100-240 V, AC input frequency: 50 - 60 Hz, Power consumption (typical): 12 W. Compliance certificates: RoHS
