ASR-9904, Cisco ASR 9000 Router, 4-slot/400G throughput/No PSU
SKU: CIS:ASR-9904 · MPN: CIS:ASR-9904 · Category: Components
Specifications
| Fabric | One per RSP: ● Active/active nonblocking operation mode in dual-RSP redundant configuration ● Fully redundant in dual-RSP redundant configuration ● Built-in service-intelligence and traffic-prioritization capability |
|---|---|
| Safety | The Cisco ASR 9904 Router is designed to meet: ● UL/CSA/IEC/EN 60950-1 ● IEC/EN 60825 Laser Safety ● ACA TS001 ● AS/NZS 60950 ● FDA Code of Federal Regulations Laser Safety |
| Airflow | Right-to-left, front-to-back with baffle |
| Thermal | One fan tray: ● 12 high-efficiency fans per tray ● Variable-speed fans for optimal thermal performance |
| Modularity | Pay-as-you-grow power for future scalability, available in AC and DC. Multiple power module types: ● 3 kW AC power module ● 2.1 kW DC power module Note: Mixing of AC and DC modules is not supported |
| Redundancy | ● AC: N+N redundancy ● DC: N+1 redundancy ● Power module redundancy ● A/B Feed redundancy |
| Power input | Worldwide ranging AC (200-240V; 50-60 Hz; 16A maximum) Worldwide ranging DC (-40 to -72V; 50A nominal, 60A maximum) |
| Power zones | No power zone restrictions Fully load-sharing power infrastructure |
| Rack mounting | 19-in. 21- and 23-in. adapters available Note: Minimum 17.75-in. opening between posts is needed for proper operation. |
| Wall mounting | No |
| ETSI standards | The Cisco ASR 9904 Router is designed to meet (qualification in progress): ● EN300 386: Telecommunications Network Equipment (EMC) ● ETSI 300 019 Storage Class 1.1 ● ETSI 300 019 Transportation Class 2.3 ● ETSI 300 019 Stationary Use Class 3.1 |
| Cabinet mounting | Yes |
| Slot orientation | Horizontal |
| Operating altitude | -60 to 4000m (up to 2000m conforms to IEC/EN/UL/CSA 60950 requirements) |
| Storage temperature | -40 to 158°F (-40 to 70°C) |
| Power module airflow | Front-to-back |
| EMC standards emission | The Cisco ASR 9904 Router is designed to meet: ● FCC Class 47CFR15 A ● ICES 003 Class A ● AS/NZS CISRP22 Class A ● CISPR 22 (EN55022) Class A ● VCCI Class A ● BSMI Class A ● IEC/EN 61000-3-12: Power Line Harmonics ● IEC/EN 61000-3-11: Voltage Fluctuations and Flicker ● EN55022: Information Technology Equipment (Emissions) ● EN 50121-4: Railway EMC |
| EMC standards immunity | The Cisco ASR 9904 Router is designed to meet: ● IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air) ● IEC/EN-61000-4-3: Radiated Immunity (10V/m) ● IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal) ● IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM) ● IEC/EN-61000-4-5: Signal Surge Ports (1kV) ● IEC/EN-61000-4-5: Surge DC Port (1kV CM, 1kV DM) ● IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms) ● IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m) ● IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations ● EN55024: Information Technology Equipment (Immunity) ● EN50082-1/EN-61000-6-1: Generic Immunity Standard ● EN 50121-4: Railway EMC |
| Physical specifications | Height: 10.38 in. (263.65x mm) (6 RU) Width: 17.57 in. (446.28 mm) Depth: 25.02 in. (635.51 mm) Weight: ● 62 lb (28.2 kg) (V2 PEM AND chassis) ● 114.05 lb (51.84 kg) (2 RSP, Fan Tray, PEM) |
| Cisco ASR 9000 Series RSP | Dual redundant RSPs with integrated fabric in 2 slots |
| Storage (relative humidity) | 5 to 93% |
| Reliability and availability | Fabric redundancy Feed redundancy Power-supply redundancy Route processor redundancy Software redundancy |
| Operating temperature (nominal) | 41 to 104°F (5 to 40°C) |
| “Commons” components | 2 RSPs 1 fan tray 1 PEM (either DC or AC) 1 fan filter |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this ASR-9904, Cisco ASR 9000 Router, 4-slot/400G throughput/No PSU (CIS:ASR-9904) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This ASR-9904, Cisco ASR 9000 Router, 4-slot/400G throughput/No PSU includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the ASR-9904, Cisco ASR 9000 Router, 4-slot/400G throughput/No PSU compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the CIS:ASR-9904.
