ASR-9903, Cisco ASR 9000 Router, 3 slots/Carrier Routing System/No PSU
SKU: CIS:ASR-9903 · MPN: CIS:ASR-9903 · Category: Components
Specifications
| Power | ● 1.6 kW DC power module (up to 4 modules), redundancy: 2+2 ● 1.6 kW AC power module (up to 4 modules), redundancy: ◦ AC high line (200-240V): 2+2 ◦ AC low line (90-130V): 3+1 Note: Mixing of AC and DC modules is not supported. |
|---|---|
| Safety | The Cisco ASR 9903 Router is designed to meet: ● UL/CSA/IEC/EN 60950-1 ● IEC/EN 60825 Laser Safety ● ACA TS001 ● AS/NZS 60950 ● FDA: Code of Federal Regulations Laser Safety |
| Airflow | Front to back |
| Ethernet | ● 10 Gbps IEEE 802.3ae compliant ● 40/100-Gbps IEEE 802.3ba compliant ● 100 Gigabit Ethernet PHY monitoring ● IEEE 802.x flow control ● Full-duplex operation ● Per-port byte and packet counters for policy drops; oversubscription drops; Cyclic Redundancy Check (CRC) error drops; packet sizes; and unicast, multicast, and broadcast packets |
| Immunity | The Cisco ASR 9903 Router is designed to meet: ● IEC/EN-61000-4-2: Electrostatic Discharge Immunity (8kV Contact, 15kV Air) ● IEC/EN-61000-4-3: Radiated Immunity (10V/m) ● IEC/EN-61000-4-4: Electrical Fast Transient Immunity (2kV Power, 1kV Signal) ● IEC/EN-61000-4-5: Surge AC Port (4kV CM, 2kV DM) ● IEC/EN-61000-4-5: Signal Ports (1kV) ● IEC/EN-61000-4-5: Surge DC Port (1kV) ● IEC/EN-61000-4-6: Immunity to Conducted Disturbances (10Vrms) ● IEC/EN-61000-4-8: Power Frequency Magnetic Field Immunity (30A/m) ● IEC/EN-61000-4-11: Voltage DIPS, Short Interruptions, and Voltage Variations ● EN 50121-4: Railway EMC |
| Redundancy | Route processor redundancy Switch fabric redundancy Power supply redundancy: Fan redundancy Software redundancy |
| Performance | ● 10-Gbps line-rate throughput per SFP+ port ● 100-Gbps line-rate throughput per QSFP28 port |
| Port density | ASR 9903 chassis with integrated ports: ● 16 QSFP28 ports capable of 10Gb, 40Gb, and 100Gb Ethernet ● 20 SFP+ ports capable of 10Gb Ethernet |
| EMC standards | The Cisco ASR 9903 Router is designed to meet: ● FCC Class A ● ICES 003 Class A ● AS/NZS 3548 Class A ● CISPR 22 (EN55022) Class A ● VCCI Class A ● BSMI Class A ● IEC/EN 61000-3-2: Power Line Harmonics ● IEC/EN 61000-3-3: Voltage Fluctuations and Flicker ● EN50121-4 Railway Applications Part 4: Emission and immunity of the signaling and telecommunications apparatus |
| RP CPU memory | SDRAM DDR4 – 32GB default |
| Rack mounting | 19-in. |
| ETSI/EN standards | The Cisco ASR 9903 Router is designed to meet: ● EN300 386: Telecommunications Network Equipment (EMC) ● ETSI 300 019 Storage Class 1.1 ● ETSI 300 019 Transportation Class 2.3 ● ETSI 300 019 Stationary Use Class 3.1 ● EN55022: Information Technology Equipment (Emissions) ● EN55024: Information Technology Equipment (Immunity) ● EN50082-1/EN-61000-6-1: Generic Immunity Standard |
| Operating altitude | –60 to 1800 m |
| Storage temperature | –40 to 158°F (–40 to 70°C) |
| Operating temperature | 41 to 104°F (5 to 40°C) Note: Limitations may apply when using high-power optics |
| Storage (relative humidity) | 5 to 95% Note: Not to exceed 0.024 kg of water per kg of dry air |
| Network Equipment Building Systems (NEBS) | The Cisco ASR 9903 Router is designed to meet: ● SR-3580: NEBS Criteria Levels (Level 3) ● GR-1089-CORE: NEBS EMC and Safety ● GR-63-CORE: NEBS Physical Protection |
| Operating humidity (nominal) (relative humidity) | 10 to 85% |
| Physical dimensions (includes ejector bracket/lever); (H x W x D); weight | ASR 9903 chassis (including 2 RPs, 4 PSUs, 4 FANs): 5.18 x 17.475 x 30 in.; 81.62 lb (131.57 mm x 443.86 mm x 762 mm; 37 kg) Note: Excluding ejector, the depth is 23.62 in/600 mm |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this ASR-9903, Cisco ASR 9000 Router, 3 slots/Carrier Routing System/No PSU (CIS:ASR-9903) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This ASR-9903, Cisco ASR 9000 Router, 3 slots/Carrier Routing System/No PSU includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the ASR-9903, Cisco ASR 9000 Router, 3 slots/Carrier Routing System/No PSU compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the CIS:ASR-9903.
