Cisco Aironet 3802I Series Access Point
Brand: Cisco · SKU: AIR-AP3802I-B-K9 · MPN: AIR-AP3802I-B-K9 · Category: Networking
The Cisco AIR-AP3802I-B-K9 is an indoor Wi-Fi 5 (802.11ac Wave 2) access point designed for large enterprise organizations and challenging high-density environments. It supports multiple gigabit uplink speeds (100 Mbps, 1 Gbps, 2.5 Gbps, and 5 Gbps) via its mGig Ethernet port, in addition to a standard Gigabit Ethernet port. It features 4x4 MU-MIMO technology with three spatial streams, supports 20, 40, 80, and 160-MHz channels, and delivers PHY data rates up to 5.2 Gbps. The 'I' in the model number indicates an Indoor deployment with internal antennas. The 'B' regulatory domain specifies the supported frequency ranges and channels (2.4 GHz: 11 channels; 5 GHz: 8 channels in 5.180-5.320 GHz, 12 channels in 5.500-5.720 GHz, 5 channels in 5.745-5.825 GHz). It includes 1024 MB DRAM and 256 MB flash memory.
Specifications
| DRAM | 1024 MB |
|---|---|
| Flash | 256 MB |
| Model | AIR-AP3802I-B-K9 |
| Antenna Type | Internal Antennas |
| Channel Widths | 20-, 40-, 80, 160-MHz |
| Ethernet Ports | 1 x 100/1000/2500/5000 Multigigabit Ethernet (RJ-45), 1 x 100/1000BASE-T autosensing (RJ-45 - AUX port) |
| Frequency Band | 2.4 GHz / 5 GHz (Dual-Band) |
| Wi-Fi Standard | 802.11a/b/g/n/ac Wave 2 |
| MIMO Technology | 4x4 MU-MIMO with three spatial streams |
| Maximum Data Rate | 5.2 Gbps (up to 2.6 Gbps per radio) |
| Regulatory Domain | B |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Warranty | Limited lifetime hardware warranty (standard for the series). |
| Weight | 4.6 lb (2.09 kg) |
| Dimensions | 8.66 x 8.68 x 2.46 in. (22 x 22 x 6.25 cm) |
Key Features
The Cisco Aironet 3802i (AIR-AP3802I-B-K9) is an enterprise-grade indoor access point supporting the 802.11ac Wave 2 standard, ideal for high-density wireless deployments requiring high throughput and reliability. Its modular design and support for MultiGigabit Ethernet uplinks (2.5/5 Gbps) prepare networks for future bandwidth demands. It features 4x4 MU-MIMO technology and internal antennas for optimal coverage in challenging indoor settings.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this Cisco Aironet 3802I Series Access Point (AIR-AP3802I-B-K9) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This Cisco Aironet 3802I Series Access Point includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the Cisco Aironet 3802I Series Access Point compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the AIR-AP3802I-B-K9.
