AIR-AP1852I-Z-K9, Cisco Wireless Access Point, 4x4:4 MIMO/802.11ac Wave 2/Internal Antenna
Brand: Cisco · SKU: AIR-AP1852I-Z-K9 · MPN: AIR-AP1852I-Z-K9 · Category: Networking
802.11ac Wave 2 Access Point, 4x4:4, Internal Antenna, Z Regulatory Domain
Specifications
| Model | AIR-AP1852I-Z-K9 |
|---|---|
| Software | Cisco Unified Wireless Network Software Release with AireOS wireless controllers: 8.1 MR1 or later for the Cisco Aironet 1850 Series Access Points |
| Indicators | Status LED: boot loader status, association status, operating status, warnings, errors |
| Interfaces | 1 x 10/100/1000BASE-T autosensing (RJ-45, PoE), 1 x 10/100/1000BASE-T autosensing (RJ-45, AUX for Link Aggregation), Management console port (RJ-45), USB 2.0 (enabled via future software) |
| Power Draw | 20.9 W Note: Power drawn from the power sourcing equipment may be higher, depending on cable length, when using PoE. |
| Description | 802.11ac Wave 2 Access Point, 4x4:4, Internal Antenna, Z Regulatory Domain |
| Environmental | Nonoperating (storage) temperature: -30°C to 70°C; Nonoperating (storage) altitude: 25°C, 15,000 ft; Operating temperature: 0°C to 40°C; Operating humidity: 10% to 90% (noncondensing); Operating altitude: 40°C, 9,843 ft |
| System Memory | 1 GB DRAM, 256 MB flash |
| Deployment Modes | Centralized local, Standalone, Sniffer, Cisco FlexConnect, Monitor, OfficeExtend, Mesh |
| Powering Options | 802.3at, Enhanced PoE, Cisco injector AIR-PWRINJ4=, Cisco local power AIR-PWR-C=, Cisco injector AIR-PWRINJ5= (802.3af only), 802.3af Note: With 802.3af PoE, the 1852e 2.4-GHz radio shifts to 2x3 from 3x4, and the USB/AUX ports are disabled on both 1852i and 1852e models. |
| Regulatory Domain | Z domain: 2.412–2.462 GHz (3 channels), 5.180–5.320 GHz (8 channels), 5.500–5.700 GHz (8 channels, excludes 5.600–5.640 GHz), 5.745–5.825 GHz (5 channels) |
| Integrated Antenna | 2.4 GHz: 3 dBi, internal omni, 360° horizontal beamwidth; 5 GHz: 5 dBi, internal omni, 360° horizontal beamwidth |
| 802.11n Capabilities | 4x4 MIMO (four spatial streams), Maximal Ratio Combining (MRC), 20/40 MHz channels, PHY up to 600 Mbps (40 MHz in 5 GHz), A-MPDU (Tx/Rx), A-MSDU (Tx/Rx), Dynamic Frequency Selection (DFS), Cyclic Shift Diversity (CSD) |
| Dimensions (W x L x H) | 8.3 x 8.3 x 2 in. (210.8 x 210.8 x 50.8 mm) (without mounting bracket) |
| Input Power Requirements | AP1850: 44 to 57 VDC; Power supply and injector: 100 to 240 VAC, 50 to 60 Hz |
| Supported Wireless LAN Controllers | Cisco 2500 Series, Cisco Wireless Controller Module for ISR G2, Cisco Wireless Services Module 2 (WiSM2) for Catalyst 6500 Series, Cisco 5500 Series, Cisco Flex 7500 Series, Cisco 8500 Series, Cisco 5760 Series, Cisco Catalyst 3650/3850 (integrated controller), Cisco Mobility Express |
| 802.11ac Wave 1 & Wave 2 Capabilities | 4x4 MIMO with four spatial streams (single user), 4x4 MIMO with three spatial streams (multi-user), MRC, 802.11ac transmit beamforming, 20/40/80 MHz channels, PHY up to 1.7 Gbps (80 MHz in 5 GHz), A-MPDU (Tx/Rx), A-MSDU (Tx/Rx), DFS, CSD support, Rogue device detection |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this AIR-AP1852I-Z-K9, Cisco Wireless Access Point, 4x4:4 MIMO/802.11ac Wave 2/Internal Antenna (AIR-AP1852I-Z-K9) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This AIR-AP1852I-Z-K9, Cisco Wireless Access Point, 4x4:4 MIMO/802.11ac Wave 2/Internal Antenna includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the AIR-AP1852I-Z-K9, Cisco Wireless Access Point, 4x4:4 MIMO/802.11ac Wave 2/Internal Antenna compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the AIR-AP1852I-Z-K9.
