ASUS M3N78-VM Socket AM2 micro ATX
Brand: ASUS · SKU: 90-MIB5B0-G0EAY00Z · MPN: 90-MIB5B0-G0EAY00Z · Category: Components
ASUS M3N78-VM, AMD, Socket AM2, 8 GB, Non-ECC, 0, 1, 0+1, 5, JBOD, micro ATX. ASUS M3N78-VM Socket AM2 micro ATX (part number 90-MIB5B0-G0EAY00Z) is an enterprise components product available from Server Tech Central. Key specifications include depth 244 mm, width 244 mm, audio chip VIA VT1708B, raid levels 0, 1, 0+1, 5, JBOD, cd/aux audio in Yes, expansion slots 1 x PCIe x16 1 x PCIe x1 2 x PCI, s/pdif out port Yes, bios memory size 64 Mbit. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| Depth | 244 mm |
|---|---|
| Width | 244 mm |
| Audio chip | VIA VT1708B |
| RAID levels | 0, 1, 0+1, 5, JBOD |
| CD/AUX audio in | Yes |
| Expansion slots | 1 x PCIe x16 1 x PCIe x1 2 x PCI |
| S/PDIF out port | Yes |
| BIOS memory size | 64 Mbit |
| Processor socket | Socket AM2 |
| CPU fan connector | Yes |
| Power source type | ATX |
| ECC сompatibility | Non-ECC |
| USB 2.0 connectors | 6 |
| HDMI ports quantity | 1 |
| PS/2 ports quantity | 1 |
| Power fan connector | Yes |
| eSATA ports quantity | 1 |
| Audio output channels | 7.1 channels |
| Number of memory slots | 4 |
| Processor manufacturer | AMD |
| USB 2.0 ports quantity | 6 |
| Maximum internal memory | 8 GB |
| Motherboard form factor | micro ATX |
| Number of SATA connectors | 5 |
| Warranty | 3-Year Warranty |
| Dimensions | 244 mm x 244 mm |
Product Description
Supports AMD Socket AM2+/AM2 for Phenom/ Athlon 64 X2 / Athlon 64 FX / Athlon 64 / Sempron / AM2+ This motherboard supports AMD AMD® Socket AM2+ multi-core processors with unique L3 cache and delivers better overclocking capabilities with less power consumption. It features dual-channel DDR2 1066 memory support and accelerates data transfer rate up to 5200MT/s via HyperTransport™ 3.0 based system bus. AMD Socket AM2 Athlon 64 X2 / Athlon 64 FX / Athlon 64/ Sempron Support This motherboard supports AMD® Socket AM2 single-core Athlon™ 64 / Sempron™ and dual-core Athlon™ 64 X2 / Athlon™ 64 FX processors with 2MB / 1MB / 512KB L2 cache based on 64-bit architecture. It features 2000 / 1600 MT/s HyperTransport™-based system bus, dual-channel un-buffered DDR2 800 memory support, and AMD® Cool ‘n’ Quiet™ Technology. HyperTransport 3.0 Support Provides 2.6 times more bandwidth than HT1.0 that radically improves system efficiency for a smoother, faster computing environment. Dual channel DDR2 1066 Support DDR2 1066 memory provides great performance for 3D graphics and other memory demanding applications on next generation memory technology. AMD Cool ´n´ Quiet! Technology M3N78-EMH HDMI supports AMD Cool ´n´ Quiet! Technology, which monitors system operation and automatically adjusts CPU voltage and frequency for a cool and quiet environment. NVIDIA® GeForce™ 8200 NVIDIA GeForce 8200 offers the latest support of Hybrid SLI Technology, DirectX10 graphics features, HD video playback with HDMI/DVI output. It also supports HyperTransport™ 3.0 interface, PCI Express™ 2.0 bus architecture, Serial ATA 3 Gb/s devices and is optimized with AMD’s latest AM2+ and multi-core CPUs to provide excellent system performance. ASUS Express Gate Surf the Internet in 5-second-boot time without entering Windows With a fast bootup speed of only 5 seconds, the ASUS Express Gate offers an optional Linux OS bootup that allows you to enjoy instant access to commonly used functions like accessing the Internet, VoIP, and Web emailing without entering the OS.
Key Features
ASUS M3N78-VM. Processor manufacturer: AMD, Processor socket: Socket AM2. Maximum internal memory: 8 GB, ECC сompatibility: Non-ECC. RAID levels: 0, 1, 0+1, 5, JBOD. Motherboard form factor: micro ATX, Audio output channels: 7.1 channels, Audio chip: VIA VT1708B. BIOS memory size: 64 Mbit
