Intellinet 8-Port PoE+ Desktop Gigabit Switch Fast Ethernet (10/100) Power over Ethernet (PoE) Black
Brand: Intellinet · SKU: 560856 · MPN: 560856 · Category: Networking
Intellinet 8-Port PoE+ Desktop Gigabit Switch, Fast Ethernet (10/100), Full duplex, Power over Ethernet (PoE), Rack mounting. Intellinet 8-Port PoE+ Desktop Gigabit Switch Fast Ethernet (10/100) Power over Ethernet (PoE) Black (part number 560856) is an enterprise switches product available from Server Tech Central. Key specifications include depth 184 mm, width 264 mm, height 44 mm, power led Yes, 10g support No, full duplex Yes, certification FCC Class B, CE, RoHS, EN 60950-1, rack mounting Yes. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| Depth | 184 mm |
|---|---|
| Width | 264 mm |
| Height | 44 mm |
| Power LED | Yes |
| 10G support | No |
| Full duplex | Yes |
| Certification | FCC Class B, CE, RoHS, EN 60950-1 |
| Rack mounting | Yes |
| LED indicators | Yes |
| Product colour | Black |
| Power connector | DC-in jack |
| AC input voltage | 100 - 240 V |
| MAC address table | 8192 entries |
| AC input frequency | 50 - 60 Hz |
| Switching capacity | 16 Gbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z |
| Power over Ethernet (PoE) | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-TX, 10BASE-T |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Warranty | 3-Year Warranty |
| Dimensions | 264 mm x 184 mm x 44 mm |
Product Description
Save Installation Time and Money with PoE The Intellinet Network Solutions 8-Port PoE+ Desktop Gigabit Switch (560856) is designed to pass both data and electrical power to a number of PoE-compatible devices via standard Cat5e or Cat6 network cables. Equipped with eight Gigabit Ethernet ports, this switch and can power wireless LAN access points and bridges, VoIP phones, IP video cameras and more while delivering network speeds of up to 1000 Mbps. Power over Ethernet 802.3at The Intellinet PoE+ Desktop Gigabit Switch supports the IEEE 802.3at protocol and is designed to inject up to 31.5 watts of power per port. IEEE802.3af- or IEEE802.3at-compliant devices attached to the switch require no additional power, thus eliminating the time and expense of electrical rewiring and minimizing the unsightly clutter caused by power supplies and adapters in awkward places such as ceilings and walls. Any mix of PoE and non-PoE devices is supported, and thanks to its short circuit, overload and high-voltage protection function, your equipment is well-protected. For devices that are not 802.3at/af compliant (legacy wireless access points or network cameras), we suggest the use of an Intellinet PoE/PoE+ Splitter. Green Ethernet Technology More often than not, a network switch does not utilize all its ports at all times. Normally, when a computer, notebook, network printer or other network device is powered down, the switch continues to consume the same amount of power as if it were active. Now, thanks to the new energy efficient IEEE 802.3az technology, the Intellinet 8-Port PoE+ Desktop Gigabit Switch detects link status to all connected devices and reduces the power usage of ports not in use. In addition, the Intellinet switch can adjust the level of power output based on the length of the network cable connected to a particular port. With the Intellinet 8-Port PoE+ Desktop Gigabit Switch you will enjoy maximum network performance, but when things slow down it automatically scales back power usage to conserve energy and save money.
Key Features
Intellinet 8-Port PoE+ Desktop Gigabit Switch. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 8. Full duplex. MAC address table: 8192 entries, Switching capacity: 16 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z. Power connector: DC-in jack. Power over Ethernet (PoE). Rack mounting
Frequently Asked Questions
Is this product genuine OEM?
Yes, this Intellinet 8-Port PoE+ Desktop Gigabit Switch Fast Ethernet (10/100) Power over Ethernet (PoE) Black (560856) is 100% genuine Intellinet hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This Intellinet 8-Port PoE+ Desktop Gigabit Switch Fast Ethernet (10/100) Power over Ethernet (PoE) Black includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the Intellinet 8-Port PoE+ Desktop Gigabit Switch Fast Ethernet (10/100) Power over Ethernet (PoE) Black compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the 560856.
