MSI Z77IA-S01 motherboard Intel Z77 LGA 1155 (Socket H2) mini ITX
Brand: MSI · SKU: Z77IA-S01 · MPN: Z77IA-S01 · Category: Components
MSI Z77IA-S01, Intel, LGA 1155 (Socket H2), Intel® Celeron®, Intel® Pentium®, i3-3xxx, i5-3xxx, i7-3xxx, DDR3-SDRAM, 16 GB. MSI Z77IA-S01 motherboard Intel Z77 LGA 1155 (Socket H2) mini ITX (part number Z77IA-S01) is an enterprise components product available from Server Tech Central. Key specifications include depth 170 mm, wi-fi Yes, width 170 mm, bios type UEFI, bluetooth Yes, audio chip Realtek ALC892, raid levels 0, 1, 5, 10, cooling type Passive. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| Depth | 170 mm |
|---|---|
| Wi-Fi | Yes |
| Width | 170 mm |
| BIOS type | UEFI |
| Bluetooth | Yes |
| Audio chip | Realtek ALC892 |
| RAID levels | 0, 1, 5, 10 |
| Cooling type | Passive |
| Ethernet LAN | Yes |
| Component for | PC |
| Dual Link DVI | Yes |
| Microphone in | Yes |
| TPM connector | Yes |
| LAN controller | Realtek RTL8111E |
| Memory channels | Dual-channel |
| S/PDIF out port | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Processor socket | LGA 1155 (Socket H2) |
| Bluetooth version | 3.0+HS |
| CPU fan connector | Yes |
| Clear CMOS jumper | Yes |
| Headphone outputs | 1 |
| Memory slots type | DIMM |
| Power source type | ATX |
| Warranty | 3-Year Warranty |
| Dimensions | 170 mm x 170 mm |
Product Description
- Supports 3rd Gen & 2nd Gen Intel® Core™ / Pentium® / Celeron® processors for LGA 1155 socket - Supports DDR3-2800(OC) Memory - USB 3.0 + SATA 6Gb/s - Military Class III: Top Quality & Stability - OC Genie II: Overclock in 1 Second - Click BIOS II: World's 1st UEFI and Software Graphical User Interface - PCI Express Gen 3: World's 1st PCI Express Gen 3 Motherboard Brand - THX TruStudio PRO: Deliver The Fullest Audio Experience - Instant OC: Real-time OC & Monitor Your System - Gaming Device Port: Optimized with Triple Gold-plating for High Frequency Gaming Devices - Fast Boot: Quickly Boot Up & Enter OS in A Few Seconds - M-Flash: Simply Update & Backup Your BIOS - Live Update 5: Easily Update The Latest BIOS & Drivers - Wi-Fi 802.11n, Bluetooth 4.0, Intel® Wireless Display Fast Boot No more waiting for entering O/S! MSI Fast Boot helps to make motherboards boot lightning fast. MSI also add the GO2BIOS button with-in. Simply click it to reset your PC and then go straight to the system BIOS. Intel® Wireless Display MSI motherboards come with an Intel® Wi-Fi / Bluetooth module which also supports Intel® WiDi. This way you can easy connect to other wireless devices in your home. The support of 802.11 b/g/n and Bluetooth 4.0 ensures that you have the fastest available transfer speed. With Intel® WiDi (stands for Wireless Display) and a WiDi receiver (not included) you can watch movies on your TV without the need for any cables. World’s 1st UEFI and software graphical user interface MSI ClickBIOS II provides a consistent user interface both in the UEFI BIOS and in Windows, it provides the most convenient way for users to control system settings and supports touchscreen control. Benefits: - Graphical User Interface, with touchscreen support - Simply click or touch and move to change settings - Full system control, including overclocking, security and information Gaming Optimized Increasing the thickness of the gold-plated layer in the 2-in-1 PS2 and optimized USB ports to 30um to meet the demand of professional gamers. Besides enhancing mouse sensitivity in games, these improved interfaces deliver a longer lifespan and better stability of connectors and total solution for e-sports mouse control in UEFI BIOS. M-Flash Compared to common motherboard which need extra BIOS chips, MSI’s M-Flash has a double advantage which doesn’t need extra components and secondly, all your BIOS data will be saved in the USB drive. The stored data does not only have backup and upgrade function, moreover it can also be seen as a portable BIOS chip which is actually able to boot up your PC. Features - Backup/Restore Your BIOS to/from Any USB Flash Disk - Avoid Unnecessary Repair Due to Accident Failures During The Upgrading Process - Earn more BIOS Lifespan by Reducing Unnecessary Rewriting Process
Key Features
MSI Z77IA-S01. Processor manufacturer: Intel, Processor socket: LGA 1155 (Socket H2), Compatible processor series: Intel® Celeron®, Intel® Pentium®. Supported memory types: DDR3-SDRAM, Maximum internal memory: 16 GB, Memory slots type: DIMM. Supported storage drive interfaces: SATA II, SATA III, RAID levels: 0, 1, 5, 10. Maximum graphics card memory: 1760 MB, Graphics card family: Intel, Maximum resolution: 2056 x 1600 pixels. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, LAN controller: Realtek RTL8111E, Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Frequently Asked Questions
Is this product genuine OEM?
Yes, this MSI Z77IA-S01 motherboard Intel Z77 LGA 1155 (Socket H2) mini ITX (Z77IA-S01) is 100% genuine MSI hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This MSI Z77IA-S01 motherboard Intel Z77 LGA 1155 (Socket H2) mini ITX includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the MSI Z77IA-S01 motherboard Intel Z77 LGA 1155 (Socket H2) mini ITX compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the Z77IA-S01.
