VIC-4FXS/DID, Cisco VIC Card, 4 FXS/DID Ports
Brand: Cisco · SKU: VIC-4FXS/DID · MPN: VIC-4FXS/DID · Category: Components
Specifications
| MTBF | 2131306 hours |
|---|---|
| Model | VIC-4FXS/DID |
| Weight | 0.34 kg |
| Compliance | FCC Class B device; CE |
| Key Features | Voice and fax integration; Caller ID support; Up to eight REN loads per card |
| Product Type | Voice Interface Card (VIC) |
| Interfaces/Ports | 4 × FXS/DID |
| Application/Usage | Voice |
| Interface Details | 4 × RJ-11 FXS/DID |
| Safety Conformance | UL1950 |
| Product Description | 4-port FXS or DID Voice Interface Card |
| Ringing Frequencies | 20 Hz, 50 Hz |
| Supported Platforms | Cisco 3845, 3825, 3745, 3725, 3640, 3660 series, 2691, 2600XM series, 1760, 1751 |
| FXS Function Support | FXS functionality supported on Cisco 2600XM, 2691, 3640, 3660, and 3700 platforms |
| Minimum Feature Sets | IP/VOX PLUS |
| Minimum IOS Versions | 3845: 12.3(11)T; 3825: 12.3(11)T; 3745: 12.2(15)ZJ; 3725: 12.2(15)ZJ; 3660 series: 12.2(15)ZJ; 2691: 12.2(15)ZJ; 2600XM series: 12.2(15)ZJ; 1760: 12.2(8)YN; 1751: 12.2(15)ZL |
| DID Signaling Formats | Immediate, delay dial, wink start |
| FXS Signaling Formats | Ground start, loop start |
| Marketing Information | 4-port high-density FXS/DID VIC supporting up to 4 FXS ports for direct connection of phones or fax machines, or up to 4 DID analog trunks. Each port can be configured as FXS or DID. Designed for small enterprise branch offices to connect analog devices while using IP for long-distance calls and PSTN for local calls and backup. |
| Address Signaling Formats | In-band DTMF; Out-of-band pulse (10 pps, 20 pps) |
| Tone Disconnect Supervision | DID power denial (caller party control, far-end disconnect) |
| FXS and DID Function Support | Both FXS and DID functionality supported on Cisco 1751 and 1760 platforms |
| Supported Carrier Modules (2600XM) | NM-1V, NM-2V, NM-HD-1V, NM-HD-2V, NM-HD-2VE, NM-HDV2-1T1/E1, NM-HDV2-2T1/E1 |
| Supported Carrier Modules (3640, 3660) | NM-1V, NM-2V, NM-HD-1V, NM-HD-2V, NM-HD-2VE |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this VIC-4FXS/DID, Cisco VIC Card, 4 FXS/DID Ports (VIC-4FXS/DID) is 100% genuine Cisco hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This VIC-4FXS/DID, Cisco VIC Card, 4 FXS/DID Ports includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the VIC-4FXS/DID, Cisco VIC Card, 4 FXS/DID Ports compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the VIC-4FXS/DID.
