VC6M1CUAA, Huawei VP96 Series Video Conferencing Hardware, AC power, 24x1080p30 ports, Media Processing Module

Brand: Huawei · SKU: VC6M1CUAA · MPN: VC6M1CUAA · Category: Components

VC6M1CUAA, Huawei VP96 Series Video Conferencing Hardware, AC power, 24x1080p30 ports, Media Processing Module
Request for Quote
In Stock • 10 units

Huawei VC6M1CUAA VP96 series VP9630-8-AC, which include frame,AC power,fan,one Media Processing Module(hardware resource for 24* 1080p30/12*1080p60 ports), 8*1080p30/4*1080p60 ports and software upgradeable

View Components Products

Specifications

ModelVC6M1CUAA
PowerAC input: 100–240 V, 50/60 Hz; DC input: None; Max power consumption: 400W
IP QoSDiffServ (DSCP), IP precedence, ARQ; SEC 3.0 (Super Error Concealment); IRC (Adaptability Intelligent Rate Control); Auto adaptation enabling; Priority settings of QoS; SNP transversal between private and public networks; H.460/Static NAT transversal
Weight30 kg
CapacityDynamic flexible ports; Up to 12 HD 1080p60 ports in CP; = 24 HD 1080p30 ports in CP; = 48 HD 720p30 ports in CP; = 96 4CIF ports in CP; VOIP port: quantity same as that of 1080p30 ports
SecurityConference password; HTTPS for secure web access; H.235 (AES256) and SRTP/TLS (AES256) encryption
Dimension86.1mm (H) × 442mm (W) × 450mm (D), 2U
Hot SpareMCU, power, network interface, chipset
Highlights (1)Embedded web, embedded GK (VP9650 & VP9630 support); Universal transcoding for telepresence; CP on each port; Auto continuous presence; Dynamic flexible ports; 48 modes of continuous presence; Ad hoc and audio/video IVR; Huawei SiteCall
Highlights (2)Schedule conferences via web (VP9650 & VP9630 support) and Outlook; Email notification; URI dialing; Plenty of conference control functions; Chair control; Endpoint control via DTMF; Message overlay; Mute video
Highlights (3)Support camera control; Support content lock; Support video source lock; Firewall traversal: H.460, static NAT, Huawei SNP, video firewall option; Integrated with UC: Huawei eSpace, Microsoft Lync 2010/OCS 2007 R2, and IBM Sametime; Intelligent negotiation: best utilization of endpoint ability; Language: English, French, German, Spanish, Russian, Chinese, Japanese
Management ToolsSupport SSH; Remote upgrade; Resource statistic; Hardware diagnosis; Support CDR (Call Detail Record); Data export and import; Support conference configuration template; Status monitor
Network ProtocolsStandards and protocols: ITU-T H.323, H.320 (VP9660 & VP9650 support), IETF SIP
Network StandardsTCP/IP, FTP/FTPS, RTP, RTCP, HTTP/HTTPS, SNMP, TELNET, SSH, DNS/DDNS
Network InterfacesGE, 1000Mb, RJ45; FE, 100Mb, RJ45; RS232, RJ45; SFP, Gigabit optical fiber interface; PRI E1 or T1: 75/120 ohm, SMB/RJ45; Line types: IP, ISDN
Per-Port Bandwidth64 kbps to 8Mbps
Operating EnvironmentOperating temperature: 0°C to 45°C; Relative humidity: 5% to 90% (non-condensing); Air pressure: 63 to 106 kPa; Reliability MTBF: > 100,000 hours; MTTR: < 0.5 hour
Approval and ComplianceCE, WEEE, RoHS, REACH, FCC, UL, VCCI-A, GOST, C-TICK
People Video ResolutionResolution: QCIF, CIF, 4CIF, 720p, 1080p; Video frame rate: 25 fps, 30 fps, 50 fps, 60 fps
Content Video ResolutionStandard resolution from VGA to 1080p60
Other Supported StandardsH.221, H.225, H.235, H.242, H.243, H.245, H.281, H.283, H.460, TIP, FECC, RFC2833, DTMF, SRTP, TLS, T.140, NTP
Audio Standards and ProtocolsAAC-LD, HWA-LD, G.722.1*, G.722.1C*, G.711, G.722, G.728, G.729A, G.729AB, G.719, iLBC; Three-channel
Video Standards and ProtocolsITU-T H.264, H.264 HP, H.264 SVC, H.263, H.263+, H.263++, H.261; ITU-T H.239, BFCP
Warranty3-Year Warranty

Key Features

  • OEM Genuine Component verified by certified technicians.
  • Clean serial number ready for service contract registration.
  • Electrostatic Discharge (ESD) safe packaging.
  • Supports hot-swapping for zero-downtime maintenance.
