TN52NS3T01, Huawei OptiX OSN Series Line Service Board, 40G AFEC DQPSK, 50GHz Channel, LC Connector
Brand: Huawei · SKU: TN52NS3T01 · MPN: TN52NS3T01 · Category: Components
40G Line Service Processing Board(AFEC,DQPSK,Tunable),50GHz(Rx1_PIN,Tx1_-5dBm~0dBm,LC)
Specifications
| MTBF | > 200,000 hours |
|---|---|
| Model | TN52NS3T01 |
| Capacity | 40G |
| Humidity | 5% to 95% (non-condensing) |
| Compliance | RoHS, CE, FCC |
| Modulation | AFEC, DQPSK |
| Tunability | Tunable |
| Return Loss | > 45 dB |
| Product Type | Line Service Processing Board |
| Connector Type | LC |
| Insertion Loss | < 4.5 dB |
| Channel Spacing | 50GHz |
| Wavelength Range | 1525-1565 nm |
| Power Consumption | < 30W |
| Transmit Power Range | Tx1_-5dBm~0dBm |
| Receive Input Sensitivity | Rx1_PIN |
| Storage Temperature Range | 40掳C to 85掳C |
| Operating Temperature Range | 5掳C to 70掳C |
| Polarization Dependent Loss | < 0.5 dB |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this TN52NS3T01, Huawei OptiX OSN Series Line Service Board, 40G AFEC DQPSK, 50GHz Channel, LC Connector (TN52NS3T01) is 100% genuine Huawei hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This TN52NS3T01, Huawei OptiX OSN Series Line Service Board, 40G AFEC DQPSK, 50GHz Channel, LC Connector includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the TN52NS3T01, Huawei OptiX OSN Series Line Service Board, 40G AFEC DQPSK, 50GHz Channel, LC Connector compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the TN52NS3T01.
