TP-Link PoE Splitter
Brand: TP-Link · SKU: TL-POE10R V1 · MPN: TL-POE10R V1 · Category: Components
TP-Link PoE Splitter, Gigabit Ethernet, 10,100,1000 Mbit/s, IEEE 802.3af, White, Power, FCC, CE
Specifications
| Depth | 54 mm |
|---|---|
| Width | 80.8 mm |
| Height | 24 mm |
| Safety | FCC, CE |
| I/O ports | PoE Port, LAN Port |
| DC-in jack | Yes |
| Output power | 12 W |
| Package depth | 165 mm |
| Package width | 198 mm |
| Auto MDI/MDI-X | Yes |
| LED indicators | Power |
| Package height | 65 mm |
| Product colour | White |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 1 |
| Networking standards | IEEE 802.3af |
| Compliance certificates | RoHS |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Gigabit Ethernet |
| Quick installation guide | Yes |
| Power over Ethernet (PoE) | Yes |
| Storage temperature (T-T) | -40 - 70 °C |
| Ethernet LAN (RJ-45) ports | 2 |
| Harmonized System (HS) code | 85044090 |
| Warranty | 3-Year Warranty |
| Dimensions | 80.8 mm x 54 mm x 24 mm |
Product Description
The PoE Splitter TL-POE10R fully complies with IEEE 802.3af standard, and can work with all IEEE 802.3af PoE compliant PSE (Power Source Equipment) or PoE Supplier Adapter, such as TP-LINK’s TL-SF1008P or TL-POE150S, or other equivalent product, to deliver 12V or 5V Direct Current to where there are no power line or outlet, where you wish to fix device such as AP, IP Camera or IP Phone, etc. - IEEE 802.3af compliant - Delivers power up to 100 meters - Optional 12V DC or 5V DC power supply - Plug-and-Play, requires no configuration
Key Features
TP-Link PoE Splitter. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3af. Product colour: White, LED indicators: Power, Safety: FCC, CE. Output power: 12 W. Compliance certificates: RoHS, Compliance industry standards: IEEE 802.3, 802.3u, 802.3af. Width: 80.8 mm, Depth: 54 mm, Height: 24 mm
Frequently Asked Questions
Is this product genuine OEM?
Yes, this TP-Link PoE Splitter (TL-POE10R V1) is 100% genuine TP-Link hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This TP-Link PoE Splitter includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the TP-Link PoE Splitter compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the TL-POE10R V1.
