APC SYMMETRA LX 16kVA N+1 Rack-mount Frame, 220/230/240V OR 380/400/415V
Brand: APC · SKU: SYAF16KRMI · MPN: SYAF16KRMI · Category: Components
APC SYMMETRA LX 16kVA N+1 Rack-mount Frame, 220/230/240V OR 380/400/415V, 16 kVA, 11200 W, 62 dB, Sealed Lead Acid (VRLA), 7.5 min, 20.3 min
Specifications
| Weight | 307.7 kg |
|---|---|
| Interface | DB-9, RS-232 |
| Noise level | 62 dB |
| Output power | 11200 W |
| Certification | C-tick,CE,EN 50091-1,EN 50091-2,EN 55022 A,EN 55024,EN 60950,GOST,IEC 60950,VDE |
| Package weight | 337.7 kg |
| Battery technology | Sealed Lead Acid (VRLA) |
| Dimensions (WxDxH) | 483 x 726 x 937 mm |
| Operating altitude | 0 - 3000 m |
| Output connections | 1xHard Wire 3-wire (H N + G) |
| Output voltage note | 220-230/240 V |
| Battery recharge time | 3 h |
| Input connection type | (1PH+N+G)/(3PH + N + G) |
| Output power capacity | 16 kVA |
| Nominal output voltage | 230 V |
| Non-operating altitude | 0 - 4500 m |
| Emergency Power Off (EPO) | Yes |
| Storage temperature (T-T) | -15 - 45 °C |
| Package dimensions (WxDxH) | 599 x 997 x 1181 mm |
| Harmonized System (HS) code | 85078000 |
| Operating temperature (T-T) | 0 - 40 °C |
| Replacement battery cartridge | SYBT5 |
| Storage relative humidity (H-H) | 0 - 95% |
| Typical backup time at full load | 7.5 min |
| Warranty | 3-Year Warranty |
| Weight | 307.7 kg |
Product Description
High performance, redundant power protection with scalable power and runtime for space-constrained server rooms, and voice and data networks.
Key Features
APC SYMMETRA LX 16kVA N+1 Rack-mount Frame, 220/230/240V OR 380/400/415V. Output power capacity: 16 kVA, Output power: 11200 W, Noise level: 62 dB. Battery technology: Sealed Lead Acid (VRLA), Typical backup time at full load: 7.5 min, Typical backup time at half load: 20.3 min. Certification: C-tick,CE,EN 50091-1,EN 50091-2,EN 55022 A,EN 55024,EN 60950,GOST,IEC 60950,VDE. Weight: 307.7 kg. Package weight: 337.7 kg
Frequently Asked Questions
Is this product genuine OEM?
Yes, this APC SYMMETRA LX 16kVA N+1 Rack-mount Frame, 220/230/240V OR 380/400/415V (SYAF16KRMI) is 100% genuine APC hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This APC SYMMETRA LX 16kVA N+1 Rack-mount Frame, 220/230/240V OR 380/400/415V includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the APC SYMMETRA LX 16kVA N+1 Rack-mount Frame, 220/230/240V OR 380/400/415V compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the SYAF16KRMI.
