Ascent SFPP-AT-LP-31-10 10G SFP+ 1310nm 10km Transceiver
Brand: Ascent Communication Technology · SKU: SFPP-AT-LP-31-10 · MPN: SFPP-AT-LP-31-10 · Category: Networking
ASCENT's SFPP-AT-LP-31-10 Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA). The transceiver consists of five sections: the LD driver, the limiting amplifier, the digital diagnostic monitor, the 1310nm FP laser and the PIN photo-detector. The module data link up to 10 km using 9/125 µm single-mode fiber. The optical output can be disabled by a TTL logic high-level input of Tx Disable, and the system also can disable the module via I2C. Tx Fault is provided to indicate that degradation of the laser. Loss Of signal (LOS) output is provided to indicate the loss of an input optical signal of receiver or the link status with partner.
Specifications
| Distance | 10 km |
|---|---|
| Connector | Duplex LC |
| Data Rate | 10.3125 Gb/s |
| Fiber Type | Single-mode Fiber (SMF) |
| Laser Type | 1310nm FP Laser |
| Monitoring | Digital Diagnostic Monitoring (DDM) |
| Wavelength | 1310 nm |
| Power Supply | Single 3.3V |
| Receiver Type | PIN Photo-detector |
| Power Dissipation | < 1.2 W |
| Operating Temperature | 0°C to 70°C |
| Warranty | 24 Months |
| Weight | 0.018 kg |
| Dimensions | 13.4mm x 8.5mm x 56.5mm |
Key Features
A high-performance 10Gb/s 1310nm SFP+ optical transceiver designed for 10km transmission over single-mode fiber, compliant with SFF-8431 and SFF-8472 standards.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this Ascent SFPP-AT-LP-31-10 10G SFP+ 1310nm 10km Transceiver (SFPP-AT-LP-31-10) is 100% genuine Ascent Communication Technology hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This Ascent SFPP-AT-LP-31-10 10G SFP+ 1310nm 10km Transceiver includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the Ascent SFPP-AT-LP-31-10 10G SFP+ 1310nm 10km Transceiver compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the SFPP-AT-LP-31-10.
