Vertiv Avocent SC 680 KVM switch Rack mounting Black
Brand: Vertiv · SKU: SC680-202 · MPN: SC680-202 · Category: Data Center
Vertiv Avocent SC 680, 2560 x 1600 pixels, Rack mounting, 5.3 W, 1U, Black
Specifications
| Depth | 233.7 mm |
|---|---|
| Width | 431.8 mm |
| Height | 43.2 mm |
| Weight | 2.7 kg |
| Certification | CE, UL 60950-1, CSA C22.2 No 60950-1, EN60950, FCC Part 15 Class B EN55022 Class B, EN55024 61000-3-3, VCCI Class B, C-Tick CISPR22, ICES-003 |
| Input voltage | 100-240 V |
| Rack capacity | 1U |
| Rack mounting | Yes |
| LED indicators | Yes |
| Product colour | Black |
| Mouse port type | USB |
| Number of users | 1 user(s) |
| Video port type | DVI-I |
| Built-in display | No |
| Audio connections | Yes |
| AC input frequency | 50 - 60 Hz |
| Keyboard port type | USB |
| Maximum resolution | 2560 x 1600 pixels |
| Storage temperature (T-T) | -20 - 50 °C |
| Maximum digital resolution | 2560 x 1600 pixels |
| Operating temperature (T-T) | 0 - 40 °C |
| Power consumption (typical) | 5.3 W |
| Number of computers controlled | 8 |
| Warranty | 3-Year Warranty |
| Weight | 2.7 kg |
| Dimensions | 431.8 mm x 233.7 mm x 43.2 mm |
Product Description
The Avocent SwitchView SC 600 and SC 700 Secure KVM Switch series offers proven, secure KVM access for any desktop environment where security is mandatory. National Information Assurance Partnership (NIAP) Common Criteria validated to EAL2+, the secure KVM switch provides multiple levels of physical security and controlled USB connectivity (limited to keyboard and mouse only). Users can reduce complexity and cost without compromising network security by consolidating multiple workstations of varying security classification levels with one keyboard, monitor and mouse. Both the SwitchView SC 600 and SC 700 switches include multiple layers of security including tamper-proof hardware security at the desktop. In addition, the Avocent KVM secure switch ensures that only the keyboard and mouse function on target computers by constantly monitoring all devices attached to the console ports. In situations where the only USB port(s) are those enabled on the target computer, the SwitchView SC KVM switch will not introduce security vulnerabilities.
Key Features
Vertiv Avocent SC 680. Keyboard port type: USB, Mouse port type: USB, Video port type: DVI-I. Maximum resolution: 2560 x 1600 pixels, Maximum digital resolution: 2560 x 1600 pixels, Number of users: 1 user(s). Product colour: Black, Rack capacity: 1U, Certification: CE, UL 60950-1, CSA C22.2 No 60950-1, EN60950, FCC Part 15 Class B EN55022 Class B, EN55024.... Input voltage: 100-240 V, AC input frequency: 50 - 60 Hz, Power consumption (typical): 5.3 W. Width: 431.8 mm, Depth: 233.7 mm, Height: 43.2 mm
Frequently Asked Questions
Is this product genuine OEM?
Yes, this Vertiv Avocent SC 680 KVM switch Rack mounting Black (SC680-202) is 100% genuine Vertiv hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This Vertiv Avocent SC 680 KVM switch Rack mounting Black includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the Vertiv Avocent SC 680 KVM switch Rack mounting Black compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the SC680-202.
