S5735S-L24FT4S-A, Huawei S5735-L Switch, 12x10/100Base-Tx/12x10/100/1000Base-T/4xGE SFP
SKU: S5735S-L24FT4S-A · MPN: S5735S-L24FT4S-A · Category: Networking
Huawei S5735-L switch, 1210/100Base-Tx ports, 1210/100/1000Base-T ports,4GE SFP ports, AC, Distribution model
Specifications
| PoE | Not supported |
|---|---|
| RPS | Not supported |
| RTC | Not supported |
| Flash | 512 MB in total. To view the available flash memory size, run the display version command. |
| Stack ports | Any 10/100/1000BASE-T ports or 1000BASE-X ports (applicable in V200R019C10 and later versions) |
| Availability | > 0.99999 |
| Memory (RAM) | 1 GB |
| Certification | EMC certification Safety certification Manufacturing certification |
| Relative humidity | 5% to 95%, noncondensing |
| Operating altitude | 0-5000 m (0-16404 ft.) |
| Rated voltage range | AC input: 100 V AC to 240 V AC, 50/60 Hz High-Voltage DC input: 240 V DC |
| Storage temperature | -40°C to +70°C (-40°F to +158°F) |
| Maximum voltage range | AC input: 90 V AC to 264 V AC, 47 Hz to 63 Hz High-Voltage DC input: 190 V DC to 290 V DC |
| Operating temperature | -5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.) NOTE: When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). The switch cannot be started when the ambient temperature is lower than 0°C (32°F). The operating temperature of the switch is -5°C to +40°C (23°F to 104°F) when it uses GE SFP optical modules with 40 km or longer transmission distance. When SFP+ copper cables or dedicated stack cables are used to set up a stack, the switch can operate in the following temperature range: -5°C to +45°C (23°F to 113°F) (installed in the ventilation cabinet, with the wind speed of at least 40 LFM) When SFP+ AOC cables or 10GE SFP+ optical modules are used to set up a stack, the switch can operate in the following temperature range: -5°C to +45°C (23°F to 113°F) (installed in the ventilation cabinet shipped with fans with a fan speed of at least 200 LFM) |
| Dimensions (H x W x D) | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.7 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.) |
| Mean time to repair (MTTR) | 2.15 hours |
| Power supply surge protection | ±6 kV in differential mode, ±6 kV in common mode |
| Service port surge protection | Common mode: ±7 kV |
| Mean time between failures (MTBF) | 55.89 years |
| Maximum power consumption (100% throughput) | 32 W |
| Noise under normal temperature (27°C, sound power) | Noise-free (no fans) |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this S5735S-L24FT4S-A, Huawei S5735-L Switch, 12x10/100Base-Tx/12x10/100/1000Base-T/4xGE SFP (S5735S-L24FT4S-A) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This S5735S-L24FT4S-A, Huawei S5735-L Switch, 12x10/100Base-Tx/12x10/100/1000Base-T/4xGE SFP includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the S5735S-L24FT4S-A, Huawei S5735-L Switch, 12x10/100Base-Tx/12x10/100/1000Base-T/4xGE SFP compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the S5735S-L24FT4S-A.
