QNAP QSW-1208-8C network switch Unmanaged Black
Brand: QNAP · SKU: QSW-1208-8C · MPN: QSW-1208-8C · Category: Networking
QNAP QSW-1208-8C, Unmanaged, Full duplex, Rack mounting
Specifications
| Depth | 233 mm |
|---|---|
| Width | 285 mm |
| Height | 43 mm |
| Weight | 2.15 kg |
| Throughput | 120 Gbit/s |
| 10G support | Yes |
| Buffer size | 128 KB |
| Full duplex | Yes |
| Noise level | 18.7 dB |
| Rubber feet | Yes |
| Switch type | Unmanaged |
| Jumbo frames | 9000 |
| Power source | AC |
| Certification | CE, FCC, VCCI, BSMI RCM, CCC |
| Rack mounting | Yes |
| LED indicators | Activity, Link, Power, Speed, Status |
| Number of fans | 2 fan(s) |
| Output current | 2.5 A |
| Package weight | 2.2 kg |
| Product colour | Black |
| Rack mount kit | Yes |
| Cables included | AC |
| AC input voltage | 100 - 240 V |
| Number of queues | 8 |
| Warranty | 3-Year Warranty |
| Weight | 2.15 kg |
| Dimensions | 285 mm x 233 mm x 43 mm |
Product Description
The QNAP QSW-1208-8C is a 12-port 10GbE unmanaged switch, allowing you to instantly upgrade your network environment at a cost-effective price. The QSW-1208-8C supports 10GBASE-T and NBASE-T standards, allowing you to take advantage of higher network speeds with your existing Cat 5e and 6a cables. Both SFP+ (fiber) and RJ45 (copper) ports are available (with 8 combo ports) for servicing a range of network needs. Compliant with IEEE 802.3az (Energy Efficient Ethernet, EEE), the QSW-1208-8C is energy efficient as well. With high performance, low latency and superb functionality, the QSW-1208-8C is the ideal choice for upgrading your home or business network to support 10GbE connections. Faster speeds using existing cables with 10GBASE-T & NBASE-T The QSW-1208-8C is compatible with 10GbE and NBASE-T technologies to provide higher transmission speeds with existing cables. Depending on cable types and their lengths, different speeds can be achieved for faster, more efficient data transfers. The QSW-1208-8C is also backwards compatible to provide connectivity with legacy devices. Flexible deployment with eight combo ports The 12-port QSW-1208-8C switch offers four SFP+ (fiber) ports, and eight SFP+/RJ45 (copper) combo ports for connecting different interfaces to the same switch. With RJ45 interfaces, 10 GbE is supported with Cat 6a (or above) cables. Alternatively, direct attach copper (DAC) cables can be used with SFP+ ports for connecting to servers inside a rack. The switching capacity of the QSW-1208-8C is 240 Gbps, guaranteeing the full potential of each port. Near-silent and energy saving With its smart cooling system, the QSW-1208-8C works quietly to ensure high-speed network performance without generating distracting background noise. IEEE 802.3az (EEE) support also reduces power consumption without sacrificing performance or functionality. By dynamically detecting link speeds and activities and adjusting accordingly, the QSW-1208-8C provides energy savings of up to 50% to minimize lifetime operational costs. Versatile installation and sleek appearance The QSW-1208-8C features a sleek modern design that blends in with existing digital homes and offices. A Rackmount Kit is also included at no extra cost for installing the QSW-1208-8C in a rack.
Key Features
QNAP QSW-1208-8C. Switch type: Unmanaged. Full duplex. MAC address table: 32000 entries, Switching capacity: 240 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3aq, IEEE 802.3az,.... Rack mounting
Technical Deployment Advisory
Target Personnel
Network Security Admins
Infrastructure Fit
Leaf-Spine Data Center Fabrics
"Network Security Admins should consider the QSW-1208-8C for Leaf-Spine Data Center Fabrics where consistent throughput and robust connectivity are mandatory."
Frequently Asked Questions
Is this product genuine OEM?
Yes, this QNAP QSW-1208-8C network switch Unmanaged Black (QSW-1208-8C) is 100% genuine QNAP hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This QNAP QSW-1208-8C network switch Unmanaged Black includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the QNAP QSW-1208-8C network switch Unmanaged Black compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the QSW-1208-8C.
