Q2P71A, HPE StoreEasy 1660 Storage, 16 LFF/Intel Xeon/RAID Controller
SKU: Q2P71A · MPN: Q2P71A · Category: Components
HPE StoreEasy 1660 Performance Storage
Specifications
| Power | 2 x 800W Platinum |
|---|---|
| Memory | 16GB (1 x HPE 16GB Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory) |
| Cooling | 6 hot-plug, high-performance redundant fans |
| Licenses | HPE iLO Advanced Premium Security Edition License with 1yr Support on Licensed Features |
| Security | Trusted Platform Module 2.0 and 2U Lockable Security Bezel |
| Processor | 1 x Intel® Xeon-Silver 4112 (2.6GHz/4-core/85W) or Intel® Xeon-Bronze 3104 (1.7GHz/6-core/85W); 2ndprocessor optional NOTE: The Xeon-Silver 4112 processor is only available on the HPE StoreEasy 1660 Performance Storage model (SKU# Q2P71A). |
| Dimensions | LFF Drives: 8.73 x 44.54 x 73.02 cm 3.44 x 17.54 x 28.75 in |
| Form Factor | 2U rack |
| Expansion Slots | 3x PCIe; optional 3 slot secondary riser NOTE: One PCIe slot occupied by M.2 SSD card. |
| Network Port(s) | 4 x 1GbE; optional FlexLOM adapter or PCIe NICs |
| Operating Systems | Microsoft® Windows Storage Server 2016, Standard Edition |
| Storage Controller | HPE Smart Array P816i-a SR Gen10 (16 Internal Lanes/4GB Cache/SmartCache) 12G SAS Modular Controller for data drives HPE Smart Array S100i SR Gen10 SW RAID for OS drives only |
| BTU Rating (Maximum ) | For 800W Power Supply: 3207 BTU/hr (at 100 VAC), 3071 BTU/hr (at 200 VAC), 3112 BTU/hr (at 240 VAC) for China Only For 500W Power Supply: 1979 BTU/hr (at 100 VAC), 1911 BTU/hr (at 200 VAC), 1965 BTU/hr (at 240 VAC) for China Only |
| Internal Drive Support | 12 LFF (3.5") hot-plug drive bays in front, optional 4LFF hot-plug mid-chassis drive cage |
| Input Requirements (per power supply) | Rated Line Voltage: 100 to 120 VAC / 200 to 240 VAC |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this Q2P71A, HPE StoreEasy 1660 Storage, 16 LFF/Intel Xeon/RAID Controller (Q2P71A) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This Q2P71A, HPE StoreEasy 1660 Storage, 16 LFF/Intel Xeon/RAID Controller includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the Q2P71A, HPE StoreEasy 1660 Storage, 16 LFF/Intel Xeon/RAID Controller compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the Q2P71A.
