Brand: Supermicro · SKU: PWS-563-1H20 · MPN: PWS-563-1H20 · Category: Components
The Supermicro PWS-563-1H20 is an 80 Plus Gold level power supply capable of supplying 560W low-line and 600W high-line output power at 90% efficiency. It features active power factor correction (PFC), automatically corrects AC input for a full range of voltages, and has a quiet fan for cooling under heavy loads. This unit is designed for 1U server applications and includes protective circuitry against over voltage, over current, and short circuiting. All materials comply with RoHS requirements. The output connector is a 20-pin ATX cable output, and it includes both 8-pin and 4-pin (12V) connectors. Cables included are: 1x 20 Pin ATX (Motherboard), 2x 8 Pin 12V (CPU), 1x 4 Pin 12V (CPU), 2x 4 Pin Legacy HDD, and 2x 4 Pin Floppy/DVD Drive.
| PFC | Yes (Active) |
|---|---|
| Cooling | 4028 PWM Controlled Ball Bearing Fan |
| +5V Output | 18A |
| Efficiency | 90% Peak |
| Protection | Over Current/Voltage, Short Circuit, Over Temperature, Input Under Voltage |
| +12V Output | 46A (100-180Vac) / 49A (180-240Vac) |
| -12V Output | 0.5A |
| Form Factor | 1U |
| +3.3V Output | 15A |
| CPU Connectors | 8-Pin and 4-Pin (12V) connectors (Both) |
| Main Connector | 20Pin ATX Cable Output (Also referred to as 24Pin in specification sheets) |
| +5V Standby Output | 3A |
| Total Power Output | 560W (Low-line) / 600W (High-line) |
| Input Current Range | 7.5A Max |
| Input Voltage Range | 100-240Vac |
| Input Frequency Range | 50-60Hz |
| Efficiency Certification | 80 Plus Gold |
| Warranty | 1 year (Varies by seller/condition) |
| Weight | N/A |
| Dimensions | 76 x 40 x 379.4mm (Alternatively listed as 11.02" x 3" x 1.57") |
A 560W/600W 1U power supply from Supermicro, certified 80 Plus Gold for high efficiency, featuring active PFC, wide AC input range support, and comprehensive protection features, making it suitable for rackmount server deployments.
Yes, this Supermicro 560W/600W 1U Multi-Output Power Supply (PWS-563-1H20) is 100% genuine Supermicro hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
This Supermicro 560W/600W 1U Multi-Output Power Supply includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the PWS-563-1H20.
