MSI PM8M2-V motherboard LGA 775 (Socket T) micro ATX
Brand: MSI · SKU: PM8M2-V · MPN: PM8M2-V · Category: Components
MSI PM8M2-V, Intel, LGA 775 (Socket T), 800 MHz, 2 GB, Fast Ethernet 10/100 Mb/s, micro ATX. MSI PM8M2-V motherboard LGA 775 (Socket T) micro ATX (part number PM8M2-V) is an enterprise components product available from Server Tech Central. Key specifications include i/o ports 4 x USB 2.0 1 x RJ45, audio output Realtek ALC655 2/6 channel S/W, expansion slots 1x AGP 8x/4X 2x PCI 2.2 32-bit PCI, processor socket LGA 775 (Socket T), power source type ATX, networking features Fast Ethernet 10/100 Mb/s, processor manufacturer Intel, maximum internal memory 2 GB. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| I/O ports | 4 x USB 2.0 1 x RJ45 |
|---|---|
| Audio output | Realtek ALC655 2/6 channel S/W |
| Expansion slots | 1x AGP 8x/4X 2x PCI 2.2 32-bit PCI |
| Processor socket | LGA 775 (Socket T) |
| Power source type | ATX |
| Networking features | Fast Ethernet 10/100 Mb/s |
| Processor manufacturer | Intel |
| Maximum internal memory | 2 GB |
| Motherboard form factor | micro ATX |
| Processor system buses supported | 800 MHz |
| Warranty | 3-Year Warranty |
Product Description
CPU Supports Intel® Pentium 4 / Celeron D processors in LGA775 package. Supports up to Pentium 4 5XX and Celeron D 3xx sequence processor. Support Intel 04B and 04A processors. Supports Intel Hyper-Threading technology. Supports up to 3.8GHz, FSB@800/533MHz Chipset VIA® P4M800 Chipset 64-bit P4 processor FSB 800MHz 64-bit DDR SDRAM memory DDR 333/400MHz 32-bit AGP (66MHz) for 8x/4x mode Supports 8X V-Link VIA® VT8237R Chipset Integrated Direct Sound AC'97 audio. Dual channel Ultra DMA 33/66/100/133 master mode EIDE controller. Integrated USB 2.0 controller. ACPI & PC2001 compliant enhanced power management Main Memory Supports four memory banks using two 184-pin DDR DIMM. Supports up to 2GB DDR333/400 SDRAM. Supports 2.5v DDR SDRAM. Slots One AGP (Accelerated Graphics Port) 8x/4X slot. Two PCI 2.2 32-bit PCI bus slots (support 3.3V/5V PCI bus interface). On-Board IDE An IDE controller on the VT8237R chipset provides IDE HDD/ CD-ROM with PIO, Bus Master and Ultra DMA133/100/66 operation modes. Can connect up to four IDE devices. Video S3 UniChrome Pro integrated graphics Audio AC'97 link controller integrated in VIA® VT8237R Realtek ALC655 2/6 channel S/W audio codec. Compliance with AC'97 v2.2 spec. Meets PC2001 audio performance requirement. LAN Realtek 8201CL Integrated Fast Ethernet PHY. Supports 10Mb/s and 100Mb/s auto-negotation operation. Compliance with PCI v2.2 and PC99 standard. Supports ACPI power management. Internal I/O Connectors ATX 20-Pin power connector 4-pin ATX 12V power connector CPU / System / Power connectors CD-in connector Clear CMOS jumper SPDIF-out connector Serial port connector (COM2) 2 x USB 2.0 connector support additional 4 ports Front panel audio connector Front panel connector 1 x Floppy disk drive connector 2 x Ultra DMA 133 IDE device connectors 2 x Serial ATA device connectors Back Panel I/O Ports 1 x Parallel 1 x Serial port (COM 1) 1 x VGA 1 x PS/2 Keyboard 1 x PS/2 Mouse 1 x Audio I/O (Line-in/Line-out/MIC) 4 x USB 2.0 1 x RJ45 LAN Jack
Key Features
MSI PM8M2-V. Processor manufacturer: Intel, Processor socket: LGA 775 (Socket T), Processor system buses supported: 800 MHz. Maximum internal memory: 2 GB. Networking features: Fast Ethernet 10/100 Mb/s. Motherboard form factor: micro ATX, Power source type: ATX. Audio output: Realtek ALC655 2/6 channel S/W
