Brand: Foxtron · SKU: PER610 · MPN: PER610 · Category: Components
The PER610 is a 6-channel relay switching unit for the Power Express (PEX) system, designed for switching loads up to 10A per channel. Outputs are formed as independent potential-free switching contacts. It can be controlled via the PEXbus, external inputs, or physical test buttons on the front panel. Programmable parameters for each relay include response on input, delayed on/off, memory, and motor control sequence. The unit features LED indicators for power supply/PEbus activity and the status of all relays. It is designed for easy installation on a DIN rail in a unified enclosure.
| Mounting | DIN rail compatible enclosure |
|---|---|
| Control System | PEXbus (RJ-11-4 connector) and external press buttons |
| Number of Outputs | 6 independent potential-free switching outputs |
| Power Requirements | 230V/50/60Hz, 50 mA |
| Insulation Strength | 2.5 kV between power and control circuits |
| Max. Load per Output | 230V/10A |
| Operating Temperature | 0 to 60 °C |
| Warranty | N/A (Information not explicitly found in search snippets) |
| Weight | 0.5 kg |
| Dimensions | (106 x 90 x 58) mm (6 modules, 17.5 mm each) |
The PER610 is a 6-channel relay unit for the PEX system, offering robust switching capability (10A per channel) with flexible control options including PEXbus integration and local button control. Its compact, DIN rail mountable design makes it suitable for centralized automation tasks.
Yes, this Foxtron PER610 Relay Unit (PER610) is 100% genuine Foxtron hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
This Foxtron PER610 Relay Unit includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the PER610.
