ASUS P5RD1-V LGA 775 (Socket T) ATX
Brand: ASUS · SKU: P5RD1-V?REFURB · MPN: P5RD1-V?REFURB · Category: Components
ASUS P5RD1-V, Intel, LGA 775 (Socket T), 4 GB, Non-ECC, 0, 1, 0+1, JBOD, Marvell 88E8001. ASUS P5RD1-V LGA 775 (Socket T) ATX (part number P5RD1-V?REFURB) is an enterprise components product available from Server Tech Central. Key specifications include depth 245 mm, width 305 mm, audio chip Realtek ALC861, raid levels 0, 1, 0+1, JBOD, lan controller Marvell 88E8001, cd/aux audio in Yes, expansion slots 1 x PCIe x16 3 x PCIe x1 3 x PCI, bios memory size 32 Mbit. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| Depth | 245 mm |
|---|---|
| Width | 305 mm |
| Audio chip | Realtek ALC861 |
| RAID levels | 0, 1, 0+1, JBOD |
| LAN controller | Marvell 88E8001 |
| CD/AUX audio in | Yes |
| Expansion slots | 1 x PCIe x16 3 x PCIe x1 3 x PCI |
| BIOS memory size | 32 Mbit |
| Processor socket | LGA 775 (Socket T) |
| CPU fan connector | Yes |
| Power source type | ATX |
| ECC сompatibility | Non-ECC |
| USB 2.0 connectors | 4 |
| Graphics controller | ATI RADEON X300 GPU |
| PS/2 ports quantity | 2 |
| Power fan connector | Yes |
| S/PDIF out connector | Yes |
| Audio output channels | 7.1 channels |
| Number of memory slots | 4 |
| Processor manufacturer | Intel |
| USB 2.0 ports quantity | 4 |
| Maximum internal memory | 4 GB |
| Motherboard form factor | ATX |
| Parallel ports quantity | 1 |
| Warranty | 3-Year Warranty |
| Dimensions | 305 mm x 245 mm |
Product Description
Intel LGA775 Pentium 4 CPU This motherboard supports the latest Pentium 4 CPU from Intel in LGA775 package. With 800MHz FSB, MB L2 cache, Hyper-Threading Technology and core-speeds up to 3.6GHz and beyond, Intel's LGA775 Pentium 4 is one of the fastest desktop processors to date. ATI RADEON XPRESS 200 Northbridge The ATI RADEON® XPRESS 200 Northbridge integrates the Radeon® X300 graphics processing unit (GPU) supporting DirectX 9 for enhanced 3D, 2D, and video capabilities. PCI Express Architecture PCI Express is the latest I/O interconnect technology that will replace the existing PCI interface. With a bus bandwidth 4 times higher than that of AGP 8X interface, PCI Express x16 bus performs much better than AGP 8X in applications such as 3D gaming. Dual-Channel DDR400 Dual-channel DDR technology doubles the bandwidth of your system memory and hence boost the system performance to out perform any memory existing solutions in the market. System bottlenecks are eliminated with balanced architecture and peak bandwidths up to 6.4GB/s. High Definition Audio Enjoy high-end sound system on your PC! The onboard 8-channel HD audio (High Definition Audio, previously codenamed Azalia) CODEC enables high-quality 192KHz/24-bit audio output. Serial ATA RAID Serial ATA is the next generation ATA specification that provides scalable performance for today and tomorrow. With up to 150MB/s data transfer rate, Serial ATA is faster than current Parallel ATA, while providing 100% software compatibility. The onboard ULIR M1573 southbridge allows RAID 0, RAID 1, RAID 0+1, JBOD configuration for four SATA connectors. ASUS CrashFree BIOS2 The CrashFree BIOS2 feature now includes the BIOS auto-recovery function in a support CD. Users can reboot their system through the support CD when a bootable disk is not available, and go through the simple BIOS auto-recovery process. ASUS motherboards now enable users to enjoy this protection feature without the need to pay for an optional ROM. C.P.R.(CPU Parameter Recall) When the system hangs due to overclocking failure, there is no need to open the case to clear CMOS data. Just simply restart the system, the BIOS would show the previous setting and then users can amend the CPU setting again.
Key Features
ASUS P5RD1-V. Processor manufacturer: Intel, Processor socket: LGA 775 (Socket T). Maximum internal memory: 4 GB, ECC сompatibility: Non-ECC. RAID levels: 0, 1, 0+1, JBOD. LAN controller: Marvell 88E8001. Motherboard form factor: ATX, Audio output channels: 7.1 channels, Audio chip: Realtek ALC861
Frequently Asked Questions
Is this product genuine OEM?
Yes, this ASUS P5RD1-V LGA 775 (Socket T) ATX (P5RD1-V?REFURB) is 100% genuine ASUS hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This ASUS P5RD1-V LGA 775 (Socket T) ATX includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the ASUS P5RD1-V LGA 775 (Socket T) ATX compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the P5RD1-V?REFURB.
