ASUS P5QL motherboard LGA 775 (Socket T) ATX
Brand: ASUS · SKU: P5QL · MPN: P5QL · Category: Components
ASUS P5QL, Intel, LGA 775 (Socket T), 16 GB, Non-ECC, Gigabit LAN, ATX. ASUS P5QL motherboard LGA 775 (Socket T) ATX (part number P5QL) is an enterprise components product available from Server Tech Central. Key specifications include depth 193 mm, width 305 mm, bios type AMI, pci slots 3, audio chip VIA VT1708S, microphone in Yes, cd/aux audio in Yes, expansion slots WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| Depth | 193 mm |
|---|---|
| Width | 305 mm |
| BIOS type | AMI |
| PCI slots | 3 |
| Audio chip | VIA VT1708S |
| Microphone in | Yes |
| CD/AUX audio in | Yes |
| Expansion slots | WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE |
| S/PDIF out port | Yes |
| BIOS memory size | 64 Mbit |
| Drivers included | Yes |
| Processor socket | LGA 775 (Socket T) |
| CPU fan connector | Yes |
| Headphone outputs | 1 |
| Power source type | ATX |
| ECC сompatibility | Non-ECC |
| USB 2.0 connectors | 3 |
| Networking features | Gigabit LAN |
| PS/2 ports quantity | 2 |
| Power fan connector | Yes |
| PCI Express x1 slots | 2 |
| S/PDIF out connector | Yes |
| Audio output channels | 7.1 channels |
| PCI Express x16 slots | 1 |
| Warranty | 3-Year Warranty |
| Dimensions | 305 mm x 193 mm |
Product Description
LGA775 Intel® Core™2 Processor Ready This motherboard supports the latest Intel® Core™2 processors in LGA775 package. It also can support Intel® next generation 45nm Multi-Core CPU. With new Intel® Core™ microarchitecture technology and 1600 / 1333 / 1066 / 800 MHz FSB, Intel® Core™2 processor is one of the most powerful and energy efficient CPU in the world. PCIe 2.0 Double Speed; Double Bandwidth & Triple Performance This motherboard supports the latest PCIe 2.0 devices for double speed and bandwidth which enhances system performance. AI Nap Minimize noise and power consumption when temporarily away! With AI Nap, users can instantly snooze your PC without terminating the tasks. System will continue operating at minimum power and noise when user is temporarily away. It keeps downloading files or running applications in quietest state while you´re sleeping. Simply click keyboard or mouse, you can swiftly wake up the system in few seconds. ASUS Express Gate Surf the Internet in 5-second-boot time without entering Windows With a fast bootup speed of only 5 seconds, the ASUS Express Gate offers an optional Linux OS bootup that allows you to enjoy instant access to commonly used functions like accessing the Internet, VoIP, and Web emailing without entering the OS. Japan-made 5000hrs VRM Solid Capacitors This motherboard uses Japan-made 5000hrs VRM high-quality conductive polymer capacitors onboard for durability, improved lifespan, and enhanced thermal capacity. CrashFree BIOS 3 Simply restore corrupted BIOS data from USB flash disk The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data from a USB flash disk containing the BIOS file. This utility saves users the cost and hassle of buying a replacement BIOS chip. EZ Flash2 Simply update BIOS from a USB flash disk before entering the OS EZ Flash is a user-friendly BIOS update utility. Simply press the pre-defined hotkey to launch this tool and update BIOS from a floppy disk before entering the OS. Noise Filter Eliminate background noise while recording This feature detects repetitive and stationary noises like computer fans, air conditioners, and other background noises then eliminates it in the incoming audio stream while recording. MyLogo2 Personalize your system with customizable boot logo You can convert your favorite photo into a 256-color boot logo for a more colorful and vivid image on your screen. S/PDIF-out on Back I/O Port This motherboard provides convenient connectivity to external home theater audio systems via coaxial S/PDIF-out (SONY-PHILIPS Digital Interface) jacks. It allows to transfer digital audio without converting to analog format and keeps the best signal quality. GreenASUS The motherboard and its packaging comply with the European Union´s Restriction on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision of creating environment-friendly and recyclable products and packaging to safeguard consumers´ health while minimizing the impact on the environment.
Key Features
ASUS P5QL. Processor manufacturer: Intel, Processor socket: LGA 775 (Socket T). Maximum internal memory: 16 GB, ECC сompatibility: Non-ECC. Networking features: Gigabit LAN. Motherboard form factor: ATX, Audio output channels: 7.1 channels, Audio chip: VIA VT1708S. BIOS type: AMI, BIOS memory size: 64 Mbit
