MTP12-FF-M5M, Juniper MTP Series Cable, 12 Fiber MMF, Reversed Polarity, 5m Length
SKU: MTP12-FF-M5M · MPN: MTP12-FF-M5M · Category: Components
MTP female to MTP female, 12 fiber, MMF cable, reversed polarity, 5m length
Specifications
| Model | MTP12-FF-M5M |
|---|---|
| Polarity | Reversed |
| Compliance | RoHS |
| Fiber Type | Multimode Fiber (MMF) |
| Bend Radius | 10x Cable Diameter |
| Return Loss | > 20 dB |
| Cable Length | 5 meters |
| Core Diameter | 50 µm |
| Connector Type | MTP Female to MTP Female |
| Fiber Standard | OM3 |
| Insertion Loss | < 0.5 dB |
| Outer Diameter | 3.0 mm |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Pulling Tension | 100 N |
| Number of Fibers | 12 |
| Cladding Diameter | 125 µm |
| Storage Temperature | -40°C to +85°C |
| Connector Durability | 500 Mating Cycles |
| Operating Wavelength | 850 nm |
| Operating Temperature | -40°C to +85°C |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this MTP12-FF-M5M, Juniper MTP Series Cable, 12 Fiber MMF, Reversed Polarity, 5m Length (MTP12-FF-M5M) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This MTP12-FF-M5M, Juniper MTP Series Cable, 12 Fiber MMF, Reversed Polarity, 5m Length includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the MTP12-FF-M5M, Juniper MTP Series Cable, 12 Fiber MMF, Reversed Polarity, 5m Length compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the MTP12-FF-M5M.
