NVIDIA Quantum-2 QM9700 400Gb/s NDR InfiniBand Switch 64-Port – MQM9700-NS2F
Brand: NVIDIA · SKU: MQM9700-NS2F · MPN: MQM9700-NS2F · Category: Components
NVIDIA Quantum-2 QM9700 MQM9700-NS2F is a managed 400Gb/s NDR InfiniBand switch with 64 NDR ports, 32 OSFP ports and P2C airflow.
Specifications
| CPU | Intel Core i3 (Coffee Lake) |
|---|---|
| Airflow | Power-to-Connector (P2C) / Forward Airflow |
| Storage | 16GB M.2 SSD |
| Port Speed | 400 Gb/s (NDR) |
| Form Factor | 1U Rack-mountable |
| Packet Rate | 66.5 Bpps |
| Switch Chip | NVIDIA Quantum-2 |
| Total Ports | 64 (via 32 OSFP connectors) |
| Power Supply | Dual 1+1 Redundant Hot-swappable AC |
| System Memory | 8GB DDR4 |
| Switching Capacity | 51.2 Tbps |
| Warranty | 3-Year Warranty |
| Weight | 14.8 kg |
| Dimensions | 1.7 x 17.2 x 26 inches |
Key Features
The NVIDIA Quantum-2 QM9700 MQM9700-NS2F is a high-performance, managed NDR InfiniBand switch designed for AI, machine learning, high-performance computing and data-center cluster environments. Based on the NVIDIA Quantum-2 switch ASIC, it provides 64 NDR ports through 32 OSFP ports , with each OSFP port supporting two 400Gb/s NDR connections. The switch delivers up to 51.2 Tb/s aggregate bidirectional throughput and more than 66.5 billion packets per second. It supports port-splitting for flexible network architectures and advanced fabric capabilities through NVIDIA MLNX-OS, including management through CLI, WebUI, SNMP and JSON interfaces. The MQM9700-NS2F uses managed operation and power-to-connector (P2C) forward airflow in a compact 1U rackmount chassis. It is well suited for demanding AI/HPC clusters and high-speed storage fabrics.
