Brand: Supermicro · SKU: MBD-X10DRH-iT · MPN: MBD-X10DRH-iT · Category: Components
Dual socket R3 (LGA 2011) motherboard supporting Intel Xeon processor E5-2600 v4/v3 family up to 145W TDP. Features the Intel C612 chipset, 16 DIMM slots supporting up to 2TB ECC 3DS LRDIMM at up to DDR4-2400MHz. It includes 1x PCI-E 3.0 x16 and 6x PCI-E 3.0 x8 slots, Intel X540 Dual port 10GBase-T, 10 SATA3 (6Gbps) ports with Intel C612 controller supporting RAID 0, 1, 5, 10, and Integrated IPMI 2.0 and KVM with Dedicated LAN. The form factor is E-ATX with dimensions of 12" x 13" (30.48cm x 33.02cm). Note: The X10DRH-CT variant includes an 8x SAS3 (12Gbps) controller with 2GB cache and RAID 0, 1, 5, 6, 10, 50, 60 support, which is not explicitly confirmed for the -iT model in the available results.
| Chipset | Intel C612 |
|---|---|
| USB Ports | 5x USB 3.0 ports, 4x USB 2.0 ports |
| SATA Ports | 10x SATA3 (6Gbps) ports w/ Intel C612 controller |
| Form Factor | E-ATX |
| Memory Type | DDR4-2400†/2133/1866/1600MHz ECC DDR4 SDRAM |
| Onboard LAN | Intel X540 Dual port 10GBase-T, 1x RJ45 Dedicated IPMI LAN port |
| Memory Slots | 16x DIMM slots |
| Serial Ports | 2x COM Ports (1 rear, 1 header), 2x fast UART 16550 serial |
| Video Output | 1x VGA port |
| Supported CPUs | Intel Xeon processor E5-2600 v4/v3 family (up to 145W TDP) |
| Expansion Slots | 1x PCI-E 3.0 x16, 6x PCI-E 3.0 x8 slots |
| Processor Socket | Dual Socket R3 (LGA 2011) |
| Max Memory Capacity | Up to 2TB† ECC 3DS LRDIMM |
| RAID Support (SATA) | RAID 0, 1, 5, 10 |
| Warranty | 36 months |
| Weight | 1.96 kg |
| Dimensions | 12" x 13" (30.48cm x 33.02cm) |
The Supermicro X10DRH-iT is a dual-processor motherboard built on the Intel C612 chipset, designed to support Intel Xeon E5-2600 v3/v4 processors. It features high-speed networking with dual 10GBase-T ports and supports large amounts of DDR4 ECC memory across 16 DIMM slots. It is suitable for demanding computational workloads due to its support for advanced processors and memory configuration.
Yes, this Supermicro X10DRH-iT Motherboard (MBD-X10DRH-iT) is 100% genuine Supermicro hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
This Supermicro X10DRH-iT Motherboard includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the MBD-X10DRH-iT.
