Brand: Intel · SKU: LGA1150-H3-INTEL · MPN: LGA1150 · Category: Components
The LGA 1150, also known as Socket H3, is a microprocessor socket designed by Intel to support its 4th-generation (Haswell) and 5th-generation (Broadwell) Core processors. Introduced in 2013 as the successor to LGA 1155, it features 1150 land contacts in a grid arrangement. This socket introduced the Fully Integrated Voltage Regulator (FIVR) on the CPU, which simplified motherboard power design and improved power efficiency. It supports dual-channel DDR3 and DDR3L memory, PCI Express 3.0, and is compatible with Intel's 8-series and 9-series chipsets. The physical design maintains a 75mm heatsink mounting hole pattern, allowing for backward compatibility with coolers designed for LGA 1155 and 1156.
| Pin Count | 1150 |
|---|---|
| Memory Support | DDR3, DDR3L (up to 1600 MHz) |
| Voltage Regulation | Fully Integrated Voltage Regulator (FIVR) |
| Compatible Chipsets | H81, B85, Q85, Q87, H87, Z87, H97, Z97, C226 |
| Lithography Support | 22nm, 14nm |
| PCI Express Version | PCI Express 3.0 |
| Supported Architectures | Haswell, Broadwell |
| Heatsink Mounting Distance | 75 mm |
| Warranty | Lifetime (Component Standard) |
| Weight | 25g |
| Dimensions | 37.5mm x 37.5mm |
Intel's LGA 1150 socket served as a bridge between the 22nm and 14nm eras. It is widely recognized for its high performance in gaming and workstation environments during the mid-2010s. The socket supports a wide range of CPUs from entry-level Celeron and Pentium chips to high-end Core i7 and Xeon E3 v3/v4 server processors.
Yes, this Intel LGA 1150 Socket H3 (LGA1150-H3-INTEL) is 100% genuine Intel hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
This Intel LGA 1150 Socket H3 includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the LGA1150-H3-INTEL.
