Brand: HPE (Hewlett Packard Enterprise) · SKU: JG898A · MPN: JG898A · Category: Networking
The HPE FlexFabric 5700 Switch Series is a family of high-performance, high-density, ultra-low-latency, top-of-rack (ToR) switches ideally suited for deployment at the server access layer of large enterprise data centers. It provides an open door for expanding your enterprise network by adding capacity with local switching and L2/Light L3 support. The switch supports IRF enhancements for spine/leaf configurations to simplify network management and expand server connectivity, delivering resilience and ease of management. IRF can reduce management complexities by up to 88% and offers a convergence time of less than 50msec. It is positioned to be a cost-effective solution, lowering TCO by up to 25% compared to competing devices. Key features include cut-through with low latency (under 1.5us 10GbE latency) and wire speed, high 1 GbE/10GbE ToR port density with 40 GbE uplinks, Layer 2 and Light Layer 3 features with Static Routing and RIP, and convergence readiness with DCB, FCoE, and TRILL
| RAM | 2 GB (SDRAM) |
|---|---|
| SFP+ Ports | 8 x 1/10Gb Ethernet (fixed) |
| Throughput | 960 Mpps or 714.2 Mpps (varies by source) |
| Device Type | Switch - L3 - Managed |
| RJ-45 Ports | 32 x 10/100/1000/10000 (10GBASE-T) |
| Flash Memory | 512 MB |
| Product Line | FlexFabric |
| Enclosure Type | Rack-mountable 1U |
| Product Series | 5700 |
| Management Ports | 1 x serial (console) RJ-45, 1 x RJ-45, 1 x USB 2.0 |
| Routing Protocol | Static IP routing, RIP, OSPF, BGP, IS-IS, MPLS |
| Operating Humidity | 10 to 90% (non-condensing) |
| QSFP+ Uplink Ports | 2 x 40Gb Ethernet |
| Switching Capacity | 1.28 Tbps |
| Management Features | IMC, CLI, sFlow, Telnet, SSH, DHCP, Web Based Management, SNMP v1, v2c, v3, RMON, HTTP, HTTPS, TFTP |
| Networking Features | Flow control, VLAN support, VPN support, Syslog support, port mirroring, IPv6 support, High Availability, STP, RSTP, MSTP, ACL support, QoS, Jumbo Frames support, MLD snooping, Dynamic ARP Inspection (DAI) |
| Package Buffer Size | 9 MB |
| Operating Temperature | 32 °F to 113 °F (0 °C to 45 °C) |
| MAC Address Table Size | 128K entries |
| Manufacturer Part Number | JG898A |
| Total Number of Network Ports | 42 |
| Max Virtual Interfaces (VLANs) | 4096 |
| Warranty | Limited lifetime warranty |
| Weight | 13 kg |
| Dimensions | 17.32 x 16.54 x 1.72 in (Dimensions HxWxD: 4.37 x 66 x 43.99 cm) |
The HPE FlexFabric 5700-32XGT-8XG-2QSFP+ Switch (JG898A) is a high-performance, rack-mountable Layer 3 managed switch designed for the server access layer in large enterprise data centers. It offers high port density with 32 x 10GBASE-T ports, 8 x 10GbE SFP+ ports, and 2 x 40GbE QSFP+ uplinks. Key advantages include ultra-low latency, high switching capacity (up to 1.28 Tbps), and simplified management via HPE Intelligent Resilient Fabric (IRF), which enhances resilience and reduces management complexity by up to 88% with sub-50msec convergence time. The switch runs Comware 7 software and supports various advanced networking features, providing a cost-effective and highly capable solution for modern data center fabrics.
Yes, this HPE FlexFabric 5700-32XGT-8XG-2QSFP+ Switch (JG898A) is 100% genuine HPE (Hewlett Packard Enterprise) hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
This HPE FlexFabric 5700-32XGT-8XG-2QSFP+ Switch includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the JG898A.
