IE-2000U-4S-G, Cisco IE 2000U Industrial Switch, 4xFE SFP/2xGE SFP
SKU: IE-2000U-4S-G · MPN: IE-2000U-4S-G · Category: Networking
IE 2000U 4 SFP FE, 2 SFP GE ports
Specifications
| RAM | 256 MB |
|---|---|
| Depth | 4.5 in |
| Ports | 4 x 100 Mbit SFP + 2 x 1000Base-X SFP (uplink) |
| Width | 3.1 in |
| Height | 5.1 in |
| Subtype | Gigabit Ethernet |
| Capacity | Virtual interfaces (VLANs): 1000 ¦ IGMP groups: 1000 |
| Features | ARP support, VLAN support, Syslog support, PIM snooping, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping, Port Aggregation Protocol (PAgP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Digital Optical Monitoring (DOM) support, Virtual Route Forwarding-Lite (VRF-Lite), MLD snooping, Dynamic ARP Inspection (DAI), Time Domain Reflectometry (TDR), Bidirectional Forwarding Detection (BFD), Uni-Directional Link Detection (UDLD), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Port Security, Remote Switch Port Analyzer (RSPAN), Hot Standby Router Protocol (HSRP) support, Management Information Base (MIB), rugged, Strict Priority Queuing (SPQ), Class of Service (CoS), 802.1x authentication, FTP client, Storm Control, Resilient Ethernet Protocol (REP), Parallel Redundancy Protocol (PRP) |
| Interfaces | 4 x 100Base-FX SFP downlink ¦ 2 x 1000Base-X SFP uplink ¦ 1 x console RJ-45 ¦ 1 x mini-USB Type B |
| Device Type | Switch - 6 ports - managed |
| Performance | Forwarding performance (64-byte packet size): 6.5 Mpps |
| Flash Memory | 128 MB |
| Enclosure Type | DIN rail mountable |
| Expansion Slots | 1 (total) / 1 (free) x SD Memory Card |
| Routing Protocol | OSPF, BGP-4, IS-IS, RIP-1, RIP-2, EIGRP, HSRP, IGMP, PIM-SM, PIM-DM, MLDv2, MLD |
| Service & Support | Limited warranty - advance parts replacement - 5 years - response time: 10 days |
| Software Included | Cisco IOS LAN Base |
| Compliant Standards | CISPR 22 Class A, CISPR 24, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, EN55024, ICES-003 Class A, UL 508, FCC Part 15 A, CSA 22.2 No. 142, VCCI Class A, KN24, KN22 Class A, ANSI/ISA.12.12.01 Class I Division 2 Groups ABCD, IEC 61850-3, IEC/UL/CSA/EN 60950-1, EN 55022 Class A, EN 60079-15:2010, IEEE 1613, CNS 13438 Class A, EN 300 386 |
| Encryption Algorithm | SSL |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
| MAC Address Table Size | 8K entries |
| Max Storage Temperature | 185 °F |
| Min Storage Temperature | -58 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this IE-2000U-4S-G, Cisco IE 2000U Industrial Switch, 4xFE SFP/2xGE SFP (IE-2000U-4S-G) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This IE-2000U-4S-G, Cisco IE 2000U Industrial Switch, 4xFE SFP/2xGE SFP includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the IE-2000U-4S-G, Cisco IE 2000U Industrial Switch, 4xFE SFP/2xGE SFP compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the IE-2000U-4S-G.
