S5735S-S24P4X-A, Huawei S5735-S Switch, 24xGE/4x10GE SFP+/PoE+/AC Power

SKU: HW:S5735S-S24P4X-A · MPN: HW:S5735S-S24P4X-A · Category: Networking

S5735S-S24P4X-A, Huawei S5735-S Switch, 24xGE/4x10GE SFP+/PoE+/AC Power
$834.44
In Stock • 10 units

Huawei S5735-S switch, 24 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports, PoE+, AC power supply

View Transceivers & Optics Products

Specifications

PoESupported
RPSNot supported
RTCSupported
ItemDescription
Flash512 MB in total. To view the available flash memory size, run the display version command.
Stack portsAny 10/100/1000BASE-T ports or 10GE SFP+ ports (applicable in V200R019C10 and later versions)
Availability> 0.99999
Memory (RAM)1 GB
CertificationEMC certification Safety certification Manufacturing certification
Relative humidity5% to 95%, noncondensing
Operating altitude0-5000 m (0-16404 ft.)
Rated voltage rangeAC input: 100 V AC to 130 V AC, 200 V AC to 240 V AC, 50/60 Hz High-Voltage DC input: 240 V DC DC input: -48 V DC to -60 V DC
Storage temperature-40°C to +70°C (-40°F to +158°F)
Maximum voltage rangeAC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz High-Voltage DC input: 190 V DC to 290 V DC DC input: -38.4 V DC to -72 V DC
Operating temperature-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.)
Dimensions (H x W x D)Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.4 in. x 16.5 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 43.6 mm x 442.0 mm x 444.2 mm (1.72 in. x 17.4 in. x 17.49 in.)
Mean time to repair (MTTR)2 hours
Power supply surge protectionUsing AC power modules: ±6 kV in differential mode, ±6 kV in common mode Using DC power modules: ±2 kV in differential mode, ±4 kV in common mode
Service port surge protectionCommon mode: ±7 kV
Short-term operating temperature-5°C to +55°C (23°F to 131°F) at an altitude of 0-1800 m (0-5906 ft.)
Mean time between failures (MTBF)59.88 years
Typical power consumption (30% of traffic load)51 W
Noise under normal temperature (27°C, sound power)< 58.9 dB(A)
Maximum power consumption (100% throughput, full speed of fans)Not providing the PoE function: 65 W 100% PoE loads: 847 W (PoE: 720 W)
Warranty3-Year Warranty

Key Features

  • OEM Genuine Component verified by certified technicians.
  • Clean serial number ready for service contract registration.
  • Electrostatic Discharge (ESD) safe packaging.
  • Supports hot-swapping for zero-downtime maintenance.

Frequently Asked Questions

Is this product genuine OEM?

Yes, this S5735S-S24P4X-A, Huawei S5735-S Switch, 24xGE/4x10GE SFP+/PoE+/AC Power (HW:S5735S-S24P4X-A) is 100% genuine OEM hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.

What warranty is included?

This S5735S-S24P4X-A, Huawei S5735-S Switch, 24xGE/4x10GE SFP+/PoE+/AC Power includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.

How long does shipping take?

We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.

Can I return this product?

Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.

Is the S5735S-S24P4X-A, Huawei S5735-S Switch, 24xGE/4x10GE SFP+/PoE+/AC Power compatible with my system?

Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the HW:S5735S-S24P4X-A.
