HP ES356AA graphics card GDDR3
Brand: HP · SKU: ES356AA · MPN: ES356AA · Category: Components
HP ES356AA, GDDR3, 512 bit, 2560 x 1600 pixels. HP ES356AA graphics card GDDR3 (part number ES356AA) is an enterprise memory product available from Server Tech Central. Key specifications include height 187.5 mm, length 419 mm, weight 1.3 kg, memory bus 512 bit, form factor Full-Height/Full-Length (FH/FL), dual link dvi Yes, bracket height Full-Height (FH), opengl version 2.0. Every unit is fully tested and backed by our standard 3-Year Warranty, with free US ground shipping and same-day dispatch on in-stock orders. Volume pricing and Net-30 terms are available for qualified businesses, government, and education.
Specifications
| Height | 187.5 mm |
|---|---|
| Length | 419 mm |
| Weight | 1.3 kg |
| I/O ports | Dual VGA analog support with DVI-to-VGA adapters. The DVI-I digital connectors are Dual Link capable. Stereoscopic 3D output connector with quad buffer support, HD Component Video (YPrPb) output with optional adapter. |
| Memory bus | 512 bit |
| Form factor | Full-Height/Full-Length (FH/FL) |
| Dual Link DVI | Yes |
| Bracket height | Full-Height (FH) |
| OpenGL version | 2.0 |
| DirectX version | 9.0 |
| Size (imperial) | 18.8 cm (7.38") |
| Mac compatibility | No |
| Weight (imperial) | 2.88 lb |
| Maximum resolution | 2560 x 1600 pixels |
| Graphics card RAMDAC | 400 MHz |
| Graphics card memory type | GDDR3 |
| Maximum analog resolution | 2048 x 1536 pixels |
| Maximum digital resolution | 1920 x 1200 pixels |
| Warranty | 3-Year Warranty |
| Weight | 1.3 kg |
Product Description
The ATI FireGL V7200 is a high-end professional 3D graphics card for workstation users that features 256 MB of high-speed video memory and multiple parallel geometry engines and shaders for high end modeling and visualization. It is ideal for high-end workstation tasks featuring complex large models with very high polygon counts, working in real-time with multiple lighting and shading effects, or challenging high resolution visualizations, such as outputting to a large LCD or plasma display. It is also HD Component Video output-enabled. The FireGL V7200 has a 512-bit Ring Bus memory controller and a Ring Bus data path. This bus is composed of two 256-bit internal rings each running in opposite directions. Two key features help cut memory latency and make the most of the high-speed GDDR3 memory - data only has to travel a maximum distance of half the ring before reaching its destination and the topology allows data, once requested, to travel around the ring without having to go back through the memory controller. It also features programmable intelligent arbitration logic that allows the memory controller to dynamically prioritize and route requests based on the current execution profile. The graphics card comes equipped with ATI Avivo™ Technology, with a High Dynamic Range (HDR) 64-bit per pixel display capability. It can produce over one trillion colors for vibrant visual fidelity and enables rich real-time lighting and contrast effects with suitable application support. The ATI FireGL V7200 is supported on the following platforms: HP xw4400, xw6400, xw8400 Workstations.
Key Features
HP ES356AA. Graphics card memory type: GDDR3, Memory bus: 512 bit. Maximum resolution: 2560 x 1600 pixels. DirectX version: 9.0, OpenGL version: 2.0, Dual Link DVI
Frequently Asked Questions
Is this product genuine OEM?
Yes, this HP ES356AA graphics card GDDR3 (ES356AA) is 100% genuine HP hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This HP ES356AA graphics card GDDR3 includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the HP ES356AA graphics card GDDR3 compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the ES356AA.
