DWDM-SFPGE-1560-61, Huawei DWDM Optical Transceiver, 2.5G/120km/LC
Brand: Huawei · SKU: DWDM-SFPGE-1560-61 · MPN: DWDM-SFPGE-1560-61 · Category: Networking
DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1560.61nm,120km,LC)
Specifications
| MTBF | 3,000,000 hours |
|---|---|
| Model | DWDM-SFPGE-1560-61 |
| Weight | 0.61 kg |
| Data Rate | 2.5G |
| Protocols | IEEE 802.3, ITU-T G.694.1 |
| Cable Type | Single-mode |
| Wavelength | 1560.61nm |
| Form Factor | eSFP |
| Hot Swappable | Yes |
| Connector Type | LC |
| RoHS Compliant | Yes |
| Modulation Format | DPSK |
| Power Consumption | 掳 1.5W |
| Temperature Range | -5掳C to 70掳C |
| Distance Supported | 120km |
| Digital Diagnostics | Yes |
| Bit Error Rate (BER) | 10^-12 |
| Optical Power Output | -1 to 4 dBm |
| Power Supply Voltage | 3.3V |
| Receiver Sensitivity | -29 dBm |
| Transmission Distance | 120km |
| DWDM-SFPGE-1560-61 Specifications Brand | Huawei |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this DWDM-SFPGE-1560-61, Huawei DWDM Optical Transceiver, 2.5G/120km/LC (DWDM-SFPGE-1560-61) is 100% genuine Huawei hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This DWDM-SFPGE-1560-61, Huawei DWDM Optical Transceiver, 2.5G/120km/LC includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the DWDM-SFPGE-1560-61, Huawei DWDM Optical Transceiver, 2.5G/120km/LC compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the DWDM-SFPGE-1560-61.
