DWDM-SFPGE-1548-51, Huawei DWDM-SFPGE Series Optical Transceiver, 2.5G, 1548.51nm, 120km
Brand: Huawei · SKU: DWDM-SFPGE-1548-51 · MPN: DWDM-SFPGE-1548-51 · Category: Networking
DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1548.51nm,120km,LC)
Specifications
| MTBF | Greater than 1,000,000 hours |
|---|---|
| Model | DWDM-SFPGE-1548-51 |
| Weight | 0.61 kg |
| TX Power | 0 to +5 dBm |
| Connector | LC |
| Data Rate | 2.5Gbps |
| Fiber Mode | Single-mode |
| Wavelength | 1548.51 nm |
| Form Factor | eSFP (Enhanced Small Form-factor Pluggable) |
| Return Loss | Greater than 20 dB |
| Max Distance | 120 km |
| Power Supply | 3.3V |
| Compatibility | IEEE 802.3ah |
| RX Sensitivity | -28 dBm |
| Temperature Range | 0掳C to 70掳C (Standard) |
| Dispersion Penalty | Less than 2 dB |
| Optical Components | DFB Laser, PIN Photodiode |
| Transmission Media | Single-mode Fiber (SMF) |
| Max Power Consumption | 1.5W |
| Regulatory Compliance | RoHS, CE, FCC |
| Digital Diagnostic Monitoring | Yes |
| DWDM-SFPGE-1548-51 Specifications Brand | Huawei |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this DWDM-SFPGE-1548-51, Huawei DWDM-SFPGE Series Optical Transceiver, 2.5G, 1548.51nm, 120km (DWDM-SFPGE-1548-51) is 100% genuine Huawei hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This DWDM-SFPGE-1548-51, Huawei DWDM-SFPGE Series Optical Transceiver, 2.5G, 1548.51nm, 120km includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the DWDM-SFPGE-1548-51, Huawei DWDM-SFPGE Series Optical Transceiver, 2.5G, 1548.51nm, 120km compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the DWDM-SFPGE-1548-51.
