DWDM-SFPGE-1540-56, Huawei DWDM Optical Transceiver, 2.5G/1540.56nm/120km
Brand: Huawei · SKU: DWDM-SFPGE-1540-56 · MPN: DWDM-SFPGE-1540-56 · Category: Networking
DWDM Optical Transceiver,eSFP,2.5G,Single-mode Module(1540.56nm,120km,LC)
Specifications
| MTBF | >1,000,000 hours |
|---|---|
| Model | DWDM-SFPGE-1540-56 |
| Weight | 0.61 kg |
| Data Rate | 2.5G |
| Compliance | SFP MSA, RoHS |
| Application | DWDM Optical Transceiver |
| Form Factor | eSFP |
| Connector Type | LC |
| Cable Fiber Type | Single-mode |
| Maximum Distance | 120 km |
| Modulation Format | NRZ |
| Power Consumption | <1.5W |
| Transmitter Power | -1 to 2 dBm |
| Optical Wavelength | 1540.56nm |
| Electrical Interface | LC |
| Receiver Sensitivity | -24 dBm |
| Transmission Distance | Up to 120 km |
| Storage Temperature Range | -40 to 85掳C |
| Operating Temperature Range | -40 to 85掳C |
| Digital Diagnostic Monitoring (DDM) | Yes |
| Warranty | 3-Year Warranty |
Key Features
- OEM Genuine Component verified by certified technicians.
- Clean serial number ready for service contract registration.
- Electrostatic Discharge (ESD) safe packaging.
- Supports hot-swapping for zero-downtime maintenance.
Frequently Asked Questions
Is this product genuine OEM?
Yes, this DWDM-SFPGE-1540-56, Huawei DWDM Optical Transceiver, 2.5G/1540.56nm/120km (DWDM-SFPGE-1540-56) is 100% genuine Huawei hardware. All our products are verified by certified technicians and come with clean serial numbers ready for service contract registration.
What warranty is included?
This DWDM-SFPGE-1540-56, Huawei DWDM Optical Transceiver, 2.5G/1540.56nm/120km includes our standard 3-Year Warranty covering all manufacturing defects. We also offer advanced replacement options for minimal downtime.
How long does shipping take?
We offer free ground shipping which typically takes 3-5 business days. Expedited shipping options are available at checkout for faster delivery.
Can I return this product?
Yes, we have a 30-day return policy on all products. Restocking fees may apply for opened items. Please see our return policy for complete details.
Is the DWDM-SFPGE-1540-56, Huawei DWDM Optical Transceiver, 2.5G/1540.56nm/120km compatible with my system?
Please check the specifications tab for detailed compatibility information. Our technical team is available to assist with compatibility questions for the DWDM-SFPGE-1540-56.
